Masses of developmental and genetic origin affecting the paediatric craniofacial skeleton
Insights into Imaging volume 9, pages 571–589 (2018)
Although rare, masses and mass-like lesions of developmental and genetic origin may affect the paediatric craniofacial skeleton. They represent a major challenge in clinical practice because they can lead to functional impairment, facial deformation and disfigurement. The most common lesions include fibrous dysplasia, dermoid cysts, vascular malformations and plexiform neurofibromas. Less common lesions include torus mandibularis and torus palatinus, cherubism, nevoid basal cell carcinoma syndrome, meningoencephalocele and nasal sinus tract. This article provides a comprehensive approach for the evaluation of children with masses or mass-like lesions of developmental and genetic origin affecting the craniofacial skeleton. Typical findings are illustrated and the respective roles of computed tomography (CT), cone beam CT (CBCT), magnetic resonance imaging (MRI) with diffusion-weighted imaging (DWI) sequences and ultrasonography (US) are discussed for the pre-therapeutic assessment, complex treatment planning and post-treatment surveillance. Key imaging findings and characteristic clinical manifestations are reviewed. Pitfalls of image interpretation are addressed and how to avoid them.
• Masses of developmental and genetic origin may severely impair the craniofacial skeleton.
• Although rare, these lesions have characteristic imaging features.
• CT, MRI and ultrasonography play a key role in their work-up.
• Recognition of pivotal imaging pearls and diagnostic pitfalls avoids interpretation errors.
Masses and mass-like lesions related to various developmental and genetic conditions can affect the developing craniofacial skeleton. The majority of masses and mass-like conditions of developmental/genetic origin are benign. Some of these conditions, such as torus palatinus and torus mandibularis, require no treatment other than alleviation of parental anxiety. Other conditions affecting the developing craniofacial skeleton, such as fibrous dysplasia, ossifying fibroma, familial gigantiform cementoma, cemento-osseous dysplasia, hereditary multiple osteochondroma or plexiform neurofibroma, may cause functional impairments due to the proximity to important neurovascular structures, organs of special senses and developing dentition. Cosmetic deformities, due to the lesion itself or due to treatment-related asymmetric facial growth, may cause a significant psychosocial impact on the patient’s life. Management of these patients, therefore, often requires close interdisciplinary work-up, precise and often complex treatment planning strategies and post-treatment surveillance into adulthood. Radiologists, as part of an interdisciplinary team, play an important role in the management of these young patients. In addition, as these rare lesions may mimic neoplasms of the craniofacial skeleton and vice versa, it is imperative to be aware of their characteristic imaging features in order to avoid unnecessary biopsy and expensive follow-up examinations.
To the best of our knowledge, a review of the imaging features of these rare masses and their impact on treatment has not been published in the English literature during the past 20 years. Most published articles on the subject are isolated case reports or small case series dealing with the clinical presentation and with patient management. This article attempts to provide a comprehensive radiological review of the most common developmental masses involving the craniofacial skeleton, along with their multimodality imaging features, clinical manifestations and the role of imaging in their pluridisciplinary management [1,2,3,4,5].
The majority of masses and mass-like conditions of developmental/genetic origin are benign. Imaging narrows down the differential diagnosis and helps in planning patient management. Traditionally, ultrasonography (US) and conventional x-ray radiography have been the mainstays of imaging in paediatric lesions. US allows differentiation between solid and cystic lesions of the facial soft tissues and enables rapid assessment of the vascularisation and localisation of the extraosseous components. The US transducer types to be used should be adapted to the small parts investigated. High-frequency linear array transducers (> 8 MHz, often > 10 MHz) yield excellent spatial resolution, but at the expense of a shallower depth of penetration. US should be ideally coupled with a Doppler evaluation. Based on the Doppler flow waveform, differentiation between infantile haemangioma, a vascular tumour gradually involuting over the years, from low-flow (venous), lymphatic or high-flow (arteriovenous) vascular malformations is facilitated. However, US has a very limited role in the evaluation of the craniofacial skeleton itself. Imaging techniques using ionising radiation, including orthopantomography (OPT), computed tomography (CT) and cone beam CT (CBCT) warrant careful use in accordance with the ALARA (As Low As Reasonably Achievable) principle . As OPT is associated with a modest radiation exposure and gives a reasonable overview of the facial skeleton, gross lesion features (osteolytic, osteosclerotic vs. mixed pattern), gross lesion margins (well-delineated vs. poorly delineated, expansile vs. non-expansile, effect on teeth structures, condyle or inferior alveolar canal), lesion location and overall effect on the skeletal growth (asymmetry and deformity) can already give important clues for the differential diagnosis. According to the size and age of the patient, a wide range of preset parameters (kV and mA) can be chosen according to vendor specifications.
After the initial evaluation, the first decision is whether to use CT or magnetic resonance imaging (MRI) for further work-up or whether the acquired US and OPT images enable reasonable patient management without further imaging. If the lesion is suspected to be of vascular nature, to have a large extraosseous component or of the type that may have a small intracranial connection (e.g. dermoid cyst), MRI is the modality of choice. Many times, however, the exact nature of the lesion is not known and the clinical presentation suggests a primary intraosseous lesion, in which case, CT becomes the imaging modality of choice. Nevertheless, it is important to note that, in cases with involvement of the skull base or prior to planning complex surgery, both MRI and CT/CBCT are required. High-resolution MRI, low-dose CT and CBCT are the standard of care for the assessment of facial masses with skeletal involvement or of primary craniofacial skeletal lesions. When performing CT or CBCT, the radiation dose is usually reduced as much as possible by limiting the scanned area to the absolute minimum, by avoiding the lens if possible and by applying a low-dose protocol . In general, CBCT gives a 2–5 times lower radiation exposure than CT, which makes it a preferred imaging modality. Although CBCT provides superb resolution of the bony and dental structures, it has poor soft tissue resolution. Its long acquisition time (up to 20s for one rotation) limits the use in young children, where motion artefacts due to limited cooperation are common. For CT and CBCT, 0.6–1-mm thin sections through the lesion are required. Coronal and sagittal reformatted images are equally obtained to precisely depict the anatomic relationship of the lesion with the adjacent structures. Three-dimensional reformatted images allowing precise pre-surgical planning are usually acquired whenever required by the maxillofacial surgeons or neurosurgeons.
MRI, in addition to having excellent soft tissue contrast, offers the advantages of multiplanar imaging and early detection of marrow oedema, as well as accurate depiction of invasion by tumours and tumour-like lesions . The use of surface coils enhances the usefulness of MRI in evaluating the intracranial connections of small lesions such as dermoid cysts and atretic encephaloceles. Multiphasic contrast-enhanced MRI (CEMRI) enables the assessment of vascular malformations, as well as tumoural and non-tumoural orbital and facial pathology . Diffusion-weighted imaging (DWI) with at least two b values (b = 0 and b = 1000) and calculation of the apparent diffusion coefficient (ADC) facilitates tissue characterisation. Typically, malignant tumours, epidermoid cysts and abscesses show restricted diffusion (high signal on b = 1000 and low signal on ADC). Benign tumours, cysts (except epidermoid) and most vascular malformations show facilitated diffusion (high signal on b = 1000 and high signal on ADC) [7, 9].
F18-Fluoro-deoxy-D-glucose (FDG) positron emission tomography CT (PET-CT) has a limited role, reserved for suspected multifocal disease manifestations or suspected sarcomatous progression of a plexiform neurofibroma into a malignant peripheral nerve sheath tumour (MPNST) [10, 11]. As an alternative to PET-CT, hybrid PET MRI provides robust multiparametric anatomic, functional and metabolic information while significantly reducing radiation exposure [12,13,14,15,16]. It also offers the possibility to accurately detect recurrent disease and to effectively follow patients in a non-invasive fashion by using a combined multiparametric approach once a malignant tumour has been identified .
Primary intraosseous lesions
Common developmental lesions of the facial skeleton include fibrous dysplasia, torus palatinus and torus mandibularis. They present as slowly progressing facial masses and palatal or mandibular palpable indurations. They may occasionally mimic neoplasms on clinical examination.
Fibrous dysplasia (FD) is typically seen in children/adolescents, with a slight predilection for girls. It is a sporadic non-neoplastic disease of the bone-forming mesenchyme in which normal lamellar bone is replaced by immature woven bone with irregular trabeculae . The condition is caused by a defect in the differentiation and maturation of osteoblasts. Histology may show secondary changes, such as aneurysmal-bone cyst-like features, or extensive myxoid changes; there is no nuclear atypia and mitoses are rare . FD leads to progressive enlargement of the affected bone, thus resulting in facial deformity, exophthalmos, visual impairment or paraesthesia due to foraminal compression. In 70–80% of cases, FD is monostotic, and in the remaining 20–30%, it is polyostotic [18, 19]. When FD affects the skull and facial bones alone, the term craniofacial FD is used . Whenever alkaline phosphatase increases dramatically in a patient with polyostotic FD, malignant degeneration should be ruled out.
In most patients with FD, CT and CBCT reveal characteristic bony expansion with a “ground-glass” appearance (Figs. 1 and 2) or mixed radiolucency, widened diploic space with outer table displacement or bubbling skull vault lesions (Fig. 2). The fibrous stroma and osteoid material are hypointense on T1, while on T2, the signal intensity may be variable. Marked or heterogeneous enhancement can be seen on CEMRI (Fig. 2). On DWI, FD typically has higher ADC values than malignant bone tumours (ADC mean in FD = 2 × 10−3 mm2/s); however, lower ADC values are not exceptional and they do not help in the differential diagnosis. On FDG PET-CT, FD may display high metabolism, mimicking malignancy . However, the characteristic ground-glass appearance of FD on CT and, whenever present, high ADC values on diffusion-weighted MRI help in differentiation [18, 19]. Although the aspect of FD on CT/CBCT is most often characteristic, a sclerotic and osteolytic pattern (so-called “pagetoid pattern”)  can render differentiation from Paget’s disease difficult. Nevertheless, the latter affects the skull vault of elderly patients and typically spares the facial skeleton. Because of an increased vascularisation of the newly formed bone in Paget’s disease, a “cotton wool” CT appearance and heterogeneous enhancement on MRI are common. Cystic forms of FD may mimic ossifying fibroma, although the latter tends to appear more mass-like, with well-defined borders and more localised than FD . Various intraosseous lesions with heterogeneous contrast enhancement may mimic FD on MRI, such as intraosseous meningioma, giant cell tumour and sclerotic metastases (prostate and lung cancer). The typical age of presentation and the characteristic CT/CBCT aspect, however, make differentiation from these entities straightforward in the paediatric age group. Although radiological findings are very characteristic but not pathognomonic of FD, they must always be correlated with patient demographics and, in rare cases, with histopathology .
The management of craniofacial FD includes a “wait and see” policy till the completion of the facial skeletal growth and surgery is performed in cases of persistent or increasing facial deformity (Fig. 1). Because complete surgical excision may lead to aesthetic and functional deficits, a more limited approach to reduce the size of the lesion is often carried out. Nevertheless, in cases with major facial disfigurement or severe optic nerve compression, resection before completion of facial growth is required . Increased risk of malignant degeneration has rendered treatment with radiotherapy obsolete (Table 1).
Cherubism is a rare autosomal dominant disorder with unknown prevalence. It results from a genetic mutation affecting bone metabolism and remodelling, and at least 15 mutation types have been identified so far [22, 23]. Multilocular pseudocysts progressively replace the lower and upper jaws, usually without other craniofacial involvement. Histology is not specific, showing fibrous tissue and osteoclast-like giant cells . The affected children develop progressive, painless and symmetric enlargement of the mandible and maxilla, and, eventually, the typical cherub face. Dental abnormalities are the most common complications, whereas ophthalmological and respiratory complications are rare . The dentomaxillofacial deformities tend to progress up to adolescence and then regress spontaneously after puberty .
OPT shows well-defined bilateral multilocular radiolucent lesions causing symmetrical bilateral enlargement of the mandible and maxilla (Fig. 3). CT/CBCT depicts expansile lytic jaw lesions separated by irregular bony septae, teeth displacement and narrowing of neural foramina (Fig. 3). MRI is reserved for complicated cases to evaluate orbital involvement and airway narrowing . Nevertheless, it has been shown that MRI may reveal additional bone changes not seen on CT or conventional x-ray images . These jaw lesions seen in cherubism have a typical “soap bubble” appearance on CT and OPT; they are of bone-related origin and should not be confused with lesions of odontogenic origin, despite involvement of the teeth and resulting dental abnormalities [5, 26].
The differential diagnosis of cherubism includes Noonan-like/multiple giant cell lesion syndrome, FD and central giant cell granuloma of the mandible and maxilla [27, 28]. Patients with Noonan-like/multiple giant cell lesion syndrome display cherubism-like jaw manifestations, short stature and developmental delay . Central giant cell granuloma is unilocular and cystic, whereas FD causes asymmetric, poorly defined bone expansion, as described above . Although cherubism spontaneously regresses after puberty, orthodontic and ophthalmologic surveillance is recommended.
Nevoid basal cell carcinoma syndrome
The triad of nevoid basal cell carcinomas, jaw cysts and bifid ribs is known as nevoid basal cell carcinoma syndrome (NBCCS) or Gorlin–Goltz syndrome [30, 31]. NBCCS is a rare autosomal dominant neurocutaneous syndrome caused by mutations in the PTCH1 gene on chromosome 9p22.3. This multisystemic disorder is characterised by predisposition to multiple basal cell carcinomas (BCCs), odontogenic keratocysts, desmoplastic variant of medulloblastoma (DVM) and skeletal, dental, ophthalmological and neurological abnormalities [32,33,34]. NBCCS patients have a life expectancy similar to that of the general population, provided that tumours and BCCs are detected and treated early .
Odontogenic keratocysts (OKCs), formerly called keratocystic odontogenic tumours , are thought to originate from the dental lamina; OKCs are the hallmark of NBCCS [5, 32]. They are seen in 75% of NBCCS patients. Multiple OKCs occur in most patients before the age of 10 years, with a peak incidence in the second and third decades of life. Clinically, the lesions are asymptomatic until they become large enough to cause jaw swelling. Common locations include the mandibular molar-ramus region (44% of cases) and the mandibular incisor-canine region (18%) . Malignant degeneration into ameloblastoma or squamous cell carcinoma has been reported [35,36,37]. OPT and CT/CBCT in OKCs typically show unilocular or multilocular cystic lesions with smooth or scalloped borders (Figs. 4 and 5). Although OKCs are the most consistent and representative lesions of NBCCS in childhood , they can incorporate the crown of an unerupted and/or displaced tooth, mimicking dentigerous cysts . Due to their extension into the soft tissues and the possibility of tooth resorption, the differentiation of OKC from ameloblastoma can be very challenging, if not impossible, on OPT, CT or CBCT. On MRI, the high signal on T2 and the weak enhancement of the thin and regular walls in OKC is very useful to differentiate these entities from multicystic forms of ameloblastoma; the latter typically show solid nodular components and irregular thick septae .
Treatment options in OKCs include surgical enucleation and cryotherapy. The reported recurrence rate after enucleation is as high as 60% . NBCCS patients tend to have associated craniofacial skeletal abnormalities, such as high arched palate, prominent palatine ridges, cleft lip/palate, prognathism and mandibular coronoid process hyperplasia [32, 34]. Further anomalies include parietal/temporal bossing (50%), macrocephaly (40%) and brachycephaly.
CT and MRI of the central nervous system (CNS) in patients with NBCCS typically reveal ectopic calcifications of the falx cerebri and tentorium cerebelli, bony bridging of the sella turcica, spotted meningeal calcification, corpus callosum agenesis/dysgenesis with/without lipoma and vermian dysgenesis (Fig. 4). Other coexisting conditions include congenital communicating hydrocephalus, DVM or other brain tumours (meningioma, oligodendroglioma, glioblastoma, craniopharyngioma) [33, 34]. As opposed to classical medulloblastoma, DVM, which occurs in the first 2 years of life, has a more favourable prognosis [33, 34]. The tumour usually presents with hydrocephalus and tends to grow directly into the brainstem. It is hypointense on T1, hyperintense on T2 and may have characteristic peripheral cysts. Enhancement can be homogeneous/heterogeneous, multinodular or star-shaped and radiating. Because of the hypercellular nature, DVMs show low ADCs (0.629 ± 0.058 × 10−3 mm2/s), therefore, allowing differentiation from glial tumours, which tend to have high ADCs .
Conventional x-rays may detect other sites of musculoskeletal involvement, such as polyostotic bone cysts and flame-like finger lesions (hamartomas), bifid, fused, splayed or missing ribs, scoliosis, spina bifida occulta, pectus deformities, polydactyly, syndactyly and Sprengel type scapula involvement . As suggested recently, radiological work-up in suspected NBCCS comprises brain MRI, OPT, cardiac and abdominal US, and skeletal survey. Major diagnostic criteria for NBCCS include multiple BCCs or one BCC before 20 years of age, jaw OKCs before 20 years of age, palmar/plantar pits, falx cerebri calcification, medulloblastoma and first-degree relatives with NBCCS. Minor criteria include rib anomalies, cleft lip/palate, other skeletal malformations, macrocephaly and ovarian/cardiac fibroma. One major criterion and molecular confirmation, two major criteria or one major and two minor criteria favour the diagnosis of NBCCS .
Torus palatinus, torus mandibularis and torus maxillaris
Torus palatinus (TP) is an exostosis occurring along either side of the midline suture of the hard palate. Torus mandibularis (TM) is an exostosis occurring along the lingual surface of the mandible, whereas torus maxillaris (TMax) occurs on the palatal or vestibular side of the alveolar process of the maxilla. According to anthropological studies, tori appear to be more common among populations living in the northern hemisphere as compared to those residing in the south . Although both tori clinically present around the age of 20 years, they are thought to be detectable during infancy too. Since both tori present as an intraoral swelling covered by intact mucosa, they may constitute a diagnostic dilemma (Fig. 6). Although tori usually have no clinical significance, they can be a cause for major parental concern. Most tori do not undergo surgery unless they interfere with dentition and function. The radiologic aspect is straightforward on CT/CBCT or MRI, which depicts a classical exostosis in a typical location (Fig. 6). Although TM and TMax are often bilateral, they may be unilateral or asymmetric, thereby rendering the diagnosis more challenging . Based on radiological findings, it is difficult to misinterpret tori as malignant bone lesions considering their typical aspect and position in association with absent involvement of the overlying soft tissues. However, in some cases, the soft tissues covering the bone growth can become ulcerated and the torus is perceived as new and worrisome, either by the patient him-/herself or at clinical examination.
Although rare, together with Langerhans cell histiocytosis (LCH), dermoid cysts (DCs) are the most common lesions of the paediatric skull. They result from epithelial sequestration during midline union of the embryonic first and second branchial arches. The generic term “dermoid cysts” comprises three entities: (1) epidermoid cyst (stratified keratinised epithelial lining without skin appendages), (2) true dermoid cyst (stratified keratinised epithelial lining with skin appendages) and (3) teratoma (showing tissues derived from the primitive germ layers) . Only about 7% of DCs are found in the head and neck region, mainly in the supraorbital region, followed by the floor of the mouth, nose, orbit and cheek [41,42,43]. Common locations of intraosseous DCs include the frontal bone (Fig. 7), maxilla and mandible [42, 44, 45].
DCs are slow-growing lesions causing bone scalloping when arising in immediate bone vicinity (Fig. 8). When arising within the bone, they present as well-delineated osteolytic lesions with sclerotic borders expanding the outer table. On CT, intraosseous DCs may show fat or fluid attenuation and internal calcification, whereas epidermoid cysts have fluid density with no fat contents or calcifications . In true dermoids, fatty components are often collected in nodules, thus giving a “sack-of-marbles” appearance . On MRI, the identification of fat within the lesion differentiates DC from LCH or other intraosseous lesions . Diffusion in DCs may be variable, and the epidermoid subgroup typically shows restricted diffusion (Fig. 7). Small asymptomatic intraosseous DCs do not require immediate treatment, whereas larger lesions may require surgery. When surgery is carried out, complete excision without rupturing the DC is mandatory to avoid recurrence or inflammation.
Nasal dermoid sinus cyst
Nasal dermoid (or dermal) sinus cyst (NDSC) includes all nasal lesions containing stratified squamous epithelium (ectoderm derivatives) and adnexal structures (mesoderm derivatives) . It is the most common midline congenital nose lesion in children, followed by glioma and encephalocele . NDSC is usually visible at birth or in early childhood. Familial cases and association with other congenital craniofacial anomalies have been described [48,49,50]. The non-compressible swelling is localised anywhere from the glabella to the columella, and is associated with a sinus opening with intermittent secretions of sebaceous material. Hair protruding through a punctum over the nasal dorsum is pathognomonic; however, this feature is present in less than 50% of patients . The cysts and sinuses may connect with an intracranial component via an abnormal foramen caecum. NDSC are, therefore, classified as superficial, intraosseous, intracranial extradural and intracranial intradural [49, 50]. Complications include recurrent infections, meningitis and brain abscess .
High-resolution CT and thin-section MRI (Fig. 9) are essential for preoperative surgical planning, and they must be performed to exclude involvement of the paranasal sinuses and intracranial extension . Indirect signs of intracranial extension include bifid or deformed crista galli, widened foramen caecum and cribriform plate defect . Contrast-enhanced MRI (Fig. 9) is essential for the differentiation between non-enhancing dermoid cyst, enhancing nasal mucosa and other masses, such as haemangioma, meningioma or teratoma . Potential diagnostic pitfalls, especially on MRI, include normal fat deposition occurring during normal bone maturation and during frontal sinus pneumatisation. These fatty changes should not be mistaken for NDSC . A further diagnostic pitfall consists in misinterpreting the normal crista galli as an NDSC. Due to the vicinity of the crista galli to the foramen caecum, it is easy to confuse the high signal intensity of the crista galli on MRI with a dermoid cyst with intracranial extension . The treatment of NDSC requires complete surgical excision, including any associated sinus tract .
Masses with secondary bone involvement
Several developmental lesions of the face or genetic conditions with subsequent development of tumours may lead to bone remodelling and scalloping of the craniofacial skeleton, thereby leading to severe functional problems. These lesions include DCs (see above), vascular malformations (VMs) and plexiform neurofibroma (PNF) .
Neurofibromas are benign peripheral nerve sheath tumours with the nerve of origin usually incorporated within the lesion . Neurofibromas include localised neurofibroma, diffuse neurofibroma and PNF . Localised neurofibromas are solitary lesions which have no association with neurofibromatosis type 1 (NF1, von Recklinghausen’s disease) . PNF is the hallmark of NF1 and is found in 30% of NF1 patients. PNF arises from major nerve branches and is characterised by diffuse long segment nerve involvement . Clinically, PNFs present as subcutaneous masses with a “bag-of-worms” consistency on palpation. PNFs have the potential for malignant transformation in up to 10% of NF1 cases . Whenever PNF shows an abrupt increase in size, a malignant transformation to MPNST needs to be ruled out .
PNF of the orbit, face and the temporal region is a rare but devastating complication of NF1. The disease is unilateral and leads to progressive bowing and scalloping of the maxillofacial skeleton (Fig. 10). Buphthalmos and sphenoid wing dysplasia (genetically determined) further contribute to vision loss, as there is prolonged compression and stretching of the optic nerve. PNFs of the orbit, temporal region and face are seen as large conglomerate masses on cross-sectional imaging. Sphenoid wing dysplasia, lambdoid suture defects, deformation and scalloping of the mandible are typical imaging findings, making the diagnosis of PNF in NF1 straightforward (Fig. 10) . PNF shows mixed or increased diffusion on ADC maps and diffusion tensor imaging with tractography reconstruction can accurately detect displacement, stretching or interruption of nerve fascicles. FDG PET-CT is a sensitive and specific tool to detect sarcomatous transformation . Sarcomatous transformation should be equally suspected in PNF with rapid increase in size.
As PNF can mimic a venous malformation on MRI, it is important to recognise the classic “target sign” of PNF (central T2 hypointensity within a multilobulated hyperintense mass). This characteristic aspect should not to be confused with phleboliths. Occasionally, PNF may be misdiagnosed as lymphatic malformation (LM) if no iv contrast material is administered. Unlike LM, PNF shows mild to moderate enhancement of the infiltrative and solid mass on contrast-enhanced CT and CEMRI.
Venous vascular malformations
Vascular malformations (VMs) of the face are rare congenital anomalies that do not regress over time and which may rapidly enlarge following trauma or endocrine changes. They are subdivided into capillary, venous, arterial and lymphatic malformations. Arterial vascular malformations (AVMs) are high-flow malformations with tortuous arteries and enlarged veins, resulting in serpiginous flow voids on T1 and T2. Capillary and venous vascular malformations (VVMs) are low-flow lesions with patchy to intense contrast enhancement and, occasionally, phleboliths. If the tissues under the skin are affected, the superficial, subcutaneous lesions may appear as slightly blue-coloured skin stains. However, most often, VVMs present as non-pulsatile compressible soft tissue swellings. As VVMs are present at birth, they usually grow with the child and may have long-term cosmetically and functionally disabling consequences, including pain, respiratory compromise and disfigurement. If the lesions are deeply located, there is only slight facial asymmetry, but no colour change. During a Valsalva manoeuvre, VVMs typically enlarge. The slow venous flow predisposes to repeated episodes of intralesional thrombosis, and sudden enlargement may occur . Increased D-dimers have been reported in 42% of patients with VVMs and are highly correlated with pain caused by thrombosis . Depending on patient symptoms, treatment includes multiple procedures (surgery, laser therapy and sclerotherapy).
The diagnosis of VVMs is made with colour Doppler US and with MRI (Fig. 11). On US, VVMs are often compressible and hypoechoic, and they present a heterogeneous sponge-like echotexture. Calcified phleboliths, although pathognomonic, are present only in 16% of cases . Monophasic flow on colour Doppler US is seen in 78% of the cases, whereas absent flow due to thrombosis or sluggish flow below the limits of detection can be seen in 16% of lesions and represents a source of diagnostic confusion . Arterial flow within the VVM is identified in 6% and is either caused by facial arteries traversing the VVM or by Masson tumour . Masson tumour (intravascular papillary endothelial hyperplasia) is an unusual benign lesion thought to represent an atypical form of thrombus organisation . On MRI, VVMs are hypointense on T1 and they occasionally display hyperintense areas caused by intralesional haemorrhage or fatty deposits. The lesions are strongly hyperintense on T2 and show variable patterns of enhancement: homogeneous/heterogeneous, slight/strong, rapid/delayed (Fig. 11). Phleboliths are present as round areas of signal voids on T1-, T2- and contrast-enhanced T1, and they can be confirmed on T2* due to the presence of calcifications and haemosiderin (Fig. 11) . The absence of phleboliths, however, does not exclude a VVM. Following trauma or spontaneous haemorrhage, VVMs may lose their typical imaging appearance due to haematoma or thrombosis . On CT, remodelling of the facial bones is common in larger lesions. Although phleboliths may be visible on conventional x-ray examinations, US and MRI, they are much better recognised on CT. Nevertheless, as mentioned above, phleboliths can be absent in VVMs, whereas rounded calcifications can also be seen in DCs. These calcifications should not be confused with phleboliths. Further diagnostic pitfalls include combined venous and lymphatic malformations and/or VVMs with large vascular channels that appear cyst-like on MRI. On MRI, the presence of vascular signal voids, which are atypical for VVMs, is due to enlarged dysplastic draining veins; the latter should not be confused with high-flow vascular lesions, i.e. AVM.
Lymphatic malformations (LMs; formerly called lymphangiomas or cystic hygromas) are benign vascular lesions, which tend to vary in size, location and extension [62, 63]. They are thought to be a developmental anomaly of the lymphatic system in which the drainage to the venous system is either poorly developed or absent, leading to stagnation of lymph with subsequent expansion and proliferation of the lymphatic system . LMs can be subdivided into three types: macrocystic (cyst diameter > 0.5 cm), microcystic (smaller lymphatic channels permeating subcutaneous tissues) and combined (macro- and microcystic) . The reported incidence of 1.2–2.8% is likely to be underestimated, as deep-seated LMs often remain undetected. Approximately 50–75% of LMs are present at birth, of which 80–90% are detected before 2 years of age and few on antenatal US. LMs, which are occult and asymptomatic at birth, may enlarge with hormonal changes, and secondary to trauma or infection . Of all LMs, 45–52% occur in the head and neck region (oral cavity, orbit and deep neck spaces).
Clinical presentations of LMs are related to infection, haemorrhage and mass effect. Mass effect can cause displacement of vital structures, thus impairing vision, breathing or swallowing. Juxtaposed bones show scalloping, sutural widening and remodelling. Trauma and infection may cause spontaneous bleeding or purulent discharge.
Optimal evaluation of superficially located LMs is possible with Doppler US. Uncomplicated LMs appear as anechoic cystic lesions with internal septations and no vascularity on colour Doppler US. US allows differentiation between LM-LMVs and venous malformations, as well as other mixed vascular lesions . CT and MRI accurately delineate the location, extent and size of LMs. On CT, LMs appear as low attenuation cystic lesions. On MRI (Fig. 12), cystic LMs display intermediate or low signal intensity on T1 and high signal intensity on T2. Intralesional fluid–fluid levels due to spontaneous haemorrhage show intermediate or high signal intensity on T1 and low signal intensity on T2. In the case of infection, DWI demonstrates restricted diffusion. LMs display slight contrast-material enhancement along cyst walls and internal septae, without opacification of dilated lymphatic channels, as opposed to slow-flowing vascular malformations, which show centripetal progressive enhancement and phleboliths (Fig. 12). As LMs may show spontaneous regression in very young children, whenever possible, treatment should be delayed until the age of 2–3 years . The management of complex cases can be challenging and requires a multidisciplinary approach. It often involves a combination of surgical resection, sclerotherapy and laser therapy .
A cephalocele is a generic term applied to several congenital or acquired conditions. Encephalocele is herniation of brain parenchyma through an osseous-dural defect of the skull base or cranial vault, whereas meningocele is herniation of meninges alone. Meningoencephalocele comprises herniation of brain parenchyma along with meninges, whereas a meningoencephalocystocele includes herniation of ventricle besides the other two . Gliocele implies herniation of gliotic brain parenchyma. Concomitant CSF leak with these conditions is common . The estimated incidence of cephalocele is 0.8–4/10,000 live births, with a well-recognised geographical variation between subtypes and female preponderance [67, 68]. Congenital cephalocele is caused by closure defect of the neural tube or by a focal failure of cartilage formation or ossification of the skull base. Common locations are the occipital and parietal bone, frontoethmoidal junction, and sphenoid and temporal bone . Although congenital cephaloceles are present at birth, they may remain clinically occult until adulthood. The clinical presentation depends on the amount of herniated cerebral tissue, on the topography of the lesion and on the associated cerebral and craniofacial anomalies . It includes CSF rhinorrhoea, facial deformity, pulsating proptosis and exophthalmos, middle ear effusion, conductive hearing loss, headache, epilepsy and ascending infections (osteomyelitis, meningitis, encephalitis and abscesses). Migrational abnormalities, corpus callosum agenesis, cleft lip and palate, coloboma and microphthalmia are common concomitant developmental anomalies . Naso-ethmoidal encephalocele should be differentiated from nasal glioma, which is a congenital non-neoplastic lesion composed of dysplastic glial tissue usually not connected to the brain and without direct communication with the subarachnoid spaces.
Imaging plays a major role for the delineation of parenchymal and bone abnormalities, and helps in determining the surgical approach (Fig. 13). High-resolution CT depicts the bony defect and shows herniation of brain parenchyma and meninges. MRI illustrates the contents of the cephalocele and the associated brain abnormalities. High-resolution three-dimensional T2 sequences, such as constructive interference steady state (CISS), fluid attenuation inversion recovery (FLAIR) and three-dimensional T1 sequences, are useful to depict the degree of parenchymal herniation . In patients with CSF rhinorrhoea and otorrhoea, detection of the site of the CSF leak is challenging and may involve several imaging modalities, including invasive procedures such as CT and MRI cisternography . For the diagnosis of active CSF leak, CT cisternography has a sensitivity of 80–85% . MRI cisternography is a better choice for patients with recurrent or inactive CSF fistulas, with a reported sensitivity as high as 100%. Laboratory studies are helpful by evaluating the content of beta-2 transferrin in nasal secretions . Occasionally, intraorbital cephaloceles can mimic an orbital dermoid or epidermoid cyst. In these situations, cephaloceles present as extraconal masses in the medial orbit without clearly identifiable connection to the intracranial contents. The treatment of cephaloceles involves a multidisciplinary approach and various surgical techniques to treat the cause, symptoms and secondary complications .
This article provides a comprehensive approach to the understanding of the clinical, radiologic and histologic features of masses and mass-like lesions of developmental and genetic origin involving the craniofacial skeleton, with emphasis on the imaging findings that are essential for diagnosis, treatment and surveillance.
Apparent diffusion coefficient
Arterial vascular malformation
Cone beam CT
Constructive interference steady state
Central nervous system
Desmoplastic variant of medulloblastoma
Fluid attenuation inversion recovery
Haematoxylin and eosin staining
Malignant peripheral nerve sheath tumour
Magnetic resonance imaging
Nevoid basal cell carcinoma syndrome
Nasal dermoid sinus cyst
Neurofibromatosis type 1
Positron emission tomography computed tomography
Venous vascular malformation
Perry KS, Tkaczuk AT, Caccamese JF Jr, Ord RA, Pereira KD (2015) Tumors of the pediatric maxillofacial skeleton: a 20-year clinical study. JAMA Otolaryngol Head Neck Surg 141:40–44
Tanrikulu R, Erol B, Haspolat K (2004) Tumors of the maxillofacial region in children: retrospective analysis and long-term follow-up outcomes of 90 patients. Turk J Pediatr 46:60–66
Iatrou I, Theologie-Lygidakis N, Tzerbos F, Schoinohoriti OK (2013) Oro-facial tumours and tumour-like lesions in Greek children and adolescents: an 11-year retrospective study. J Craniomaxillofac Surg 41:437–443
Trosman SJ, Krakovitz PR (2015) Pediatric maxillary and mandibular tumors. Otolaryngol Clin North Am 48:101–119
Avril L, Lombardi T, Ailianou A et al (2014) Radiolucent lesions of the mandible: a pattern-based approach to diagnosis. Insights Imaging 5:85–101
Greenwood TJ, Lopez-Costa RI, Rhoades PD et al (2015) CT dose optimization in pediatric radiology: a multiyear effort to preserve the benefits of imaging while reducing the risks. Radiographics 35:1539–1554
Becker M, Stefanelli S, Rougemont AL, Poletti PA, Merlini L (2017) Non-odontogenic tumors of the facial bones in children and adolescents: role of multiparametric imaging. Neuroradiology 59:327–342
Purohit BS, Vargas MI, Ailianou A et al (2016) Orbital tumours and tumour-like lesions: exploring the armamentarium of multiparametric imaging. Insights Imaging 7:43–68
Abdel Razek AA, Gaballa G, Elhawarey G, Megahed AS, Hafez M, Nada N (2009) Characterization of pediatric head and neck masses with diffusion-weighted MR imaging. Eur Radiol 19:201–208
Kaste SC (2011) PET-CT in children: where is it appropriate? Pediatr Radiol 41(Suppl 2):509–513
McCarville MB (2009) PET-CT imaging in pediatric oncology. Cancer Imaging 9:35–43
Becker M, Zaidi H (2014) Imaging in head and neck squamous cell carcinoma: the potential role of PET/MRI. Br J Radiol 87:20130677
Varoquaux A, Rager O, Poncet A et al (2014) Detection and quantification of focal uptake in head and neck tumours: (18)F-FDG PET/MR versus PET/CT. Eur J Nucl Med Mol Imaging 41:462–475
Schäfer JF, Gatidis S, Schmidt H et al (2014) Simultaneous whole-body PET/MR imaging in comparison to PET/CT in pediatric oncology: initial results. Radiology 273:220–231
Zaidi H, Becker M (2016) The promise of hybrid PET\/MRI: technical advances and clinical applications. IEEE Signal Process Mag 33:67–85
Vargas MI, Becker M, Garibotto V et al (2013) Approaches for the optimization of MR protocols in clinical hybrid PET/MRI studies. MAGMA 26:57–69
Becker M, Varoquaux AD, Combescure C et al (2018) Local recurrence of squamous cell carcinoma of the head and neck after radio(chemo)therapy: diagnostic performance of FDG-PET/MRI with diffusion-weighted sequences. Eur Radiol 28:651–663
Fitzpatrick KA, Taljanovic MS, Speer DP et al (2004) Imaging findings of fibrous dysplasia with histopathologic and intraoperative correlation. AJR Am J Roentgenol 182:1389–1398
Hanifi B, Samil KS, Yasar C, Cengiz C, Ercan A, Ramazan D (2013) Craniofacial fibrous dysplasia. Clin Imaging 37:1109–1115
Stegger L, Juergens KU, Kliesch S, Wormanns D, Weckesser M (2007) Unexpected finding of elevated glucose uptake in fibrous dysplasia mimicking malignancy: contradicting metabolism and morphology in combined PET/CT. Eur Radiol 17:1784–1786
Kolomvos N, Theologie-Lygidakis N, Christopoulos P, Iatrou I (2013) Benign fibro-osseous lesions of the jaws in children. A 12-year retrospective study. J Craniomaxillofac Surg 41:574–580
Baskin B, Bowdin S, Ray PN (2011) Cherubism. GeneReviews® [Internet]
Jiao Y, Zhou M, Yang Y, Zhou J, Duan X (2015) Cherubism misdiagnosed as giant cell tumor: a case report and review of literature. Int J Clin Exp Med 8:4656–4663
Cariati P, Monsalve Iglesias F, Fernández Solís J, Valencia Laseca A, Martinez Lara I (2017) Cherubism. A case report. Reumatol Clin 13:352–353
Jain V, Sharma R (2006) Radiographic, CT and MRI features of cherubism. Pediatr Radiol 36:1099–1104
Wright JM, Vered M (2017) Update from the 4th edition of the World Health Organization Classification of Head and Neck Tumours: odontogenic and maxillofacial bone tumors. Head Neck Pathol 11:68–77
Romano AA, Allanson JE, Dahlgren J et al (2010) Noonan syndrome: clinical features, diagnosis, and management guidelines. Pediatrics 126:746–759
Eyselbergs M, Vanhoenacker F, Hintjens J, Dom M, Devriendt K, Van Dijck H (2014) Unilateral giant cell lesion of the jaw in Noonan syndrome. JBR-BTR 97:90–93
Roberts AE, Allanson JE, Tartaglia M, Gelb BD (2013) Noonan syndrome. Lancet 381:333–342
Gorlin RJ, Goltz RW (1960) Multiple nevoid basal-cell epithelioma, jaw cysts and bifid rib. A syndrome. N Engl J Med 262:908–912
Gorlin RJ (2004) Nevoid basal cell carcinoma (Gorlin) syndrome. Genet Med 6:530–539
Ramesh M, Krishnan R, Chalakkal P, Paul G (2015) Gorlin–Goltz syndrome: case report and literature review. J Oral Maxillofac Pathol 19:267
Lo Muzio L (2008) Nevoid basal cell carcinoma syndrome (Gorlin syndrome). Orphanet J Rare Dis 3:32
Thalakoti S, Geller T (2015) Basal cell nevus syndrome or Gorlin syndrome. Handb Clin Neurol 132:119–128
Jalali E, Ferneini EM, Rengasamy K, Tadinada A (2017) Squamous cell carcinoma arising within a maxillary odontogenic keratocyst: a rare occurrence. Imaging Sci Dent 47:135–140
Eversole LR, Sabes WR, Rovin S (1975) Aggressive growth and neoplastic potential of odontogenic cysts: with special reference to central epidermoid and mucoepidermoid carcinomas. Cancer 35:270–282
Moubayed SP, Khorsandi A, Urken ML (2016) Radiological challenges in distinguishing keratocystic odontogenic tumor from ameloblastoma: an extraordinary occurrence in the same patient. Am J Otolaryngol 37:362–364
Liu HQ, Yin X, Li Y et al (2012) MRI features in children with desmoplastic medulloblastoma. J Clin Neurosci 19:281–285
Haugen LK (1992) Palatine and mandibular tori. A morphologic study in the current Norwegian population. Acta Odontol Scand 50:65–77
Kün-Darbois JD, Guillaume B, Chappard D (2017) Asymmetric bone remodeling in mandibular and maxillary tori. Clin Oral Investig 21:2781–2788
Brown RE, Harave S (2016) Diagnostic imaging of benign and malignant neck masses in children-a pictorial review. Quant Imaging Med Surg 6:591–604
Sahoo NK, Choudhary AK, Srinivas V, Tomar K (2015) Dermoid cysts of maxillofacial region. Med J Armed Forces India 71:S389–S394
La’porte SJ, Juttla JK, Lingam RK (2011) Imaging the floor of the mouth and the sublingual space. Radiographics 31:1215–1230
Ciappetta P, Artico M, Salvati M, Raco A, Gagliardi FM (1990) Intradiploic epidermoid cysts of the skull: report of 10 cases and review of the literature. Acta Neurochir (Wien) 102:33–37
Stokes RB, Saunders CJ, Thaller SR (1996) Bregmatic epidermoid inclusion cyst eroding both calvarial tables. J Craniofac Surg 7:148–150
Woo EK, Connor SE (2007) Computed tomography and magnetic resonance imaging appearances of cystic lesions in the suprahyoid neck: a pictorial review. Dentomaxillofac Radiol 36:451–458
Re M, Tarchini P, Macrì G, Pasquini E (2012) Endonasal endoscopic approach for intracranial nasal dermoid sinus cysts in children. Int J Pediatr Otorhinolaryngol 76:1217–1222
El-Fattah AM, Naguib A, El-Sisi H, Kamal E, Tawfik A (2016) Midline nasofrontal dermoids in children: a review of 29 cases managed at Mansoura University Hospitals. Int J Pediatr Otorhinolaryngol 83:88–92
Zapata S, Kearns DB (2006) Nasal dermoids. Curr Opin Otolaryngol Head Neck Surg 14:406–411
Hartley BE, Eze N, Trozzi M et al (2015) Nasal dermoids in children: a proposal for a new classification based on 103 cases at Great Ormond Street Hospital. Int J Pediatr Otorhinolaryngol 79:18–22
Barkovich AJ, Vandermarck P, Edwards MS, Cogen PH (1991) Congenital nasal masses: CT and MR imaging features in 16 cases. AJNR Am J Neuroradiol 12:105–116
Boyd JB, Mulliken JB, Kaban LB, Upton J 3rd, Murray JE (1984) Skeletal changes associated with vascular malformations. Plast Reconstr Surg 74:789–797
Korf BR (1999) Plexiform neurofibromas. Am J Med Genet 89:31–37
Coulon A, Milin S, Laban E, Debiais C, Jamet C, Goujon JM (2009) Pathologic characteristics of the most frequent peripheral nerve tumors. Neurochirurgie 55:454–458
Zhu Y, Ghosh P, Charnay P, Burns DK, Parada LF (2002) Neurofibromas in NF1: Schwann cell origin and role of tumor environment. Science 296:920–922
Prada CE, Rangwala FA, Martin LJ et al (2012) Pediatric plexiform neurofibromas: impact on morbidity and mortality in neurofibromatosis type 1. J Pediatr 160:461–467
Hosoi K (1931) Multiple neurofibromatosis (von Recklinghausen’s disease): with special reference to malignant transformation. Arch Surg 22:258–281
Jacquemin C, Bosley TM, Liu D, Svedberg H, Buhaliqa A (2002) Reassessment of sphenoid dysplasia associated with neurofibromatosis type 1. AJNR Am J Neuroradiol 23:644–648
Basu S, Nair N (2006) Potential clinical role of FDG-PET in detecting sarcomatous transformation in von Recklinghausen’s disease: a case study and review of the literature. J Neurooncol 80:91–95
Olivieri B, White CL, Restrepo R, McKeon B, Karakas SP, Lee EY (2016) Low-flow vascular malformation pitfalls: from clinical examination to practical imaging evaluation—part 2, venous malformation mimickers. AJR Am J Roentgenol 206:952–962
Craig KA, Escobar E, Inwards CY, Kransdorf MJ (2016) Imaging characteristics of intravascular papillary endothelial hyperplasia. Skeletal Radiol 45:1467–1472
Elluru RG, Balakrishnan K, Padua HM (2014) Lymphatic malformations: diagnosis and management. Semin Pediatr Surg 23:178–185
Zhou Q, Zheng JW, Mai HM et al (2011) Treatment guidelines of lymphatic malformations of the head and neck. Oral Oncol 47:1105–1109
Colbert SD, Seager L, Haider F, Evans BT, Anand R, Brennan PA (2013) Lymphatic malformations of the head and neck-current concepts in management. Br J Oral Maxillofac Surg 51:98–102
Settecase F, Harnsberger HR, Michel MA, Chapman P, Glastonbury CM (2014) Spontaneous lateral sphenoid cephaloceles: anatomic factors contributing to pathogenesis and proposed classification. AJNR Am J Neuroradiol 35:784–789
Vaezi A, Snyderman CH, Saleh HA, Carrau RL, Zanation A, Gardner P (2011) Pseudomeningoceles of the sphenoid sinus masquerading as sinus pathology. Laryngoscope 121:2507–2513
Naidich TP, Altman NR, Braffman BH, McLone DG, Zimmerman RA (1992) Cephaloceles and related malformations. AJNR Am J Neuroradiol 13:655–690
Wind JJ, Caputy AJ, Roberti F (2008) Spontaneous encephaloceles of the temporal lobe. Neurosurg Focus 25:E11
Stefanelli S, Barnaure I, Momjian S et al (2014) Incidental intrasphenoidal encephalocele(ise). J Neuroradiol 41:358–360
Ma J, Huang Q, Li X et al (2015) Endoscopic transnasal repair of cerebrospinal fluid leaks with and without an encephalocele in pediatric patients: from infants to children. Childs Nerv Syst 31:1493–1498
Conflict of interest
The authors declare that there is no conflict of interests regarding the publication of this paper.
