Chest CT examinations in patients presenting with acute chest pain: a pictorial review
Insights into Imaging volume 6, pages719–728(2015)
Acute chest pain (ACP) is one of the most common presenting symptoms at the emergency department. The differential diagnosis is vast. To exclude life-threatening causes, radiologists encounter an increasing amount of thoracic computed tomography (CT) examinations including CT angiography of the heart and great vessels. The dual- and triple-rule CT examinations are currently implemented in clinical practice. We retrospectively identified chest CT examinations in the setting of acute chest pain in our hospitals and collected a variety of common and uncommon cases. In this pictorial essay, we present the most educative cases from patients who presented with acute chest pain in the emergency department of our hospitals and for whom a thoracic CT was ordered. When aortic emergencies, acute coronary syndrome, and pulmonary embolism are excluded, these cases may help the radiologist to suggest alternative diagnoses in the diagnostic challenge of acute chest pain.
• The number of chest CT examinations for ACP is increasing.
• Chest CT examinations may help suggesting alternative diagnosis in ACP.
• Radiologists should be aware of the differential diagnosis of ACP.
Acute chest pain is one of the most common presenting symptoms at the emergency department (ED), up to 10 % of all ED admissions in the United States . The differential diagnosis is vast and includes aortic, coronary artery, pericardial and pulmonary diseases such as pulmonary embolism, thereby frequently providing a diagnostic challenge. Although the primary diagnostic goal is to exclude life threatening causes such as acute coronary artery syndrome (ACS, referred to as a symptomatic coronary artery stenosis or myocardial infarction, i.e., reduced coronary artery flow leading to acute cardiac ischemic states), in only a minority of the patients with acute chest pain ACS is there ultimately a confirmed diagnosis, yielding a substantial number of possible alternative diagnosis. On the contrary, missing the diagnosis of ACS accounts for frequent litigation and is reported in patients with atypical presentations, such as those of younger age or without electrocardiography (ECG) abnormalities . In the last decade, computed tomography (CT) imaging has become a powerful tool in the diagnostic process, aiming to decrease false negative outcomes and providing clues for an alternative diagnosis.
Different modalities have been proposed in the workup of suspected ACS. In the (sub) acute setting the availability and speed of ECG gated CT has lead mainly to an increase in acute thoracic CT exams. A variety of scanning protocols have been developed and extensively studied for this diagnostic question. The expected increase in chest “rule-out” CT scans in patients with acute chest pain stresses the need for radiologists to be aware of an alternative diagnosis. We retrospectively identified patients who presented with acute chest pain at the ED in our hospitals, and selected the most educative cases, not aiming to present a complete overview of all causes of chest pain. The present pictorial essay reviews, thus, some of the alternative diagnoses, focused on aortic, coronary artery, pericardial and pulmonary diseases, which may help the general radiologist in clinical practice.
Aortic emergencies have been recently reviewed . Complementary, incidentally found, aneurysms of the thoracic aorta are frequently encountered and can be associated with acute chest pain as well. The upper limit of the aortic diameter is dependent on patient sex, age, and body size. Aortic aneurysms may directly compromise a coronary artery and cause acute chest pain. The causes of aortic dilatation include loss of elastic fibers due to aging (degenerative dilatation, as in the present case), or genetic causes such as Marfan syndrome, Ehlers-Danlos, bicuspid aortic valve disease, or Loeys Dietz syndrome. The normal growth rate of the ascending aorta is approximately 0.07 to 0.2 cm per year, although this expansion may be accelerated by increasing aortic size, in hypertensive patients and in patients with connective tissue diseases  Fig. 1.
Aortic aneurysm; sinus of valsalva aneurysm
Most sinus of Valsalva aneurysms are congenital and associated with other congenital cardiac anomalies, accounting for only 0.1-3.5 % of all congenital heart defects . Although these aneurysms may be found incidentally , some may present with angina pectoris by compromising the lumen of the right coronary artery , or may present as acute coronary syndrome after rupture, most often in the right ventricle leading to a large shunt  . Pericardial effusion may be observed as well, Fig. 2.
Aortitis is a non-specific term, defined as inflammatory infiltration of the aortic wall. The causes are divided into infectious and non-infectious . The most common causes of aortitis are noninfectious etiologies such as Takayasu’s and Giant cell arteritis although other rheumatologic related diseases may be implicated. Aortitis is a relatively uncommon disease entity, but the non-specific clinical presentation (including chest pain) should raise early suspicion. Imaging aims to review the extent of the disease, wall abnormalities, and luminal changes . Moreover, aortitis is associated with an increased risk for acute aortic syndrome including aortic dissection. For diagnosing aortitis, CT is a well-accepted first modality of choice and shows irregular thickening of the aortic wall, which may enhance focal dilatation or stenosis. Moreover, periaortic fat stranding can be seen. Fluid collections, soft tissue mass, and extensive fat stranding may indicate infectious aortitis Fig. 3.
Coronary artery disease
Coronary anomalies are relatively rare (0.3-5.6 %) and are usually classified as benign or malignant . The anomalous interarterial course of a coronary artery, i.e., course between the aorta and pulmonary artery at the level of the right ventricular outflow tract is considered a malignant variant, although typically they are found incidentally and are, thus, asymptomatic. The course of the vessel, however, may result in compression and ischemia, especially during exercise when the aortic and pulmonary root distends. The most common variant is an anomalous RCA originating from the left coronary cusp, in which patients with a high interarterial course are more prone to present with chest pain . A single coronary artery, when coursing interarterially, or the intramural course of a proximal coronary artery through the aortic wall is a malignant variant as well, leading to ACS via the same mechanism. A rare variant that also may lead to ACS is ostial atresia of the left main artery. The left coronary circulation is then supplied with blood from collaterals via the right coronary artery, Fig. 4.
Coronary artery fistula
Coronary artery fistulas (CAF) form a group of congenital abnormalities characterised by an abnormal connection with a cardiac chamber or great vessel. CAF is encountered in approximately 0.3 %-1.3 % of patients undergoing diagnostic coronary angiography . Although most CAF represent isolated communications, multiple fistulas have been described. Most CAF present as an incidental finding. Nevertheless, depending on the degree of left-to-right shunting, right ventricular dysfunction may be present. Significant shunting may lead to exertional dyspnoea and chest pain, especially during physical activity. The diagnosis of CAF has been traditionally made by coronary angiography . However, since the distal part of the fistula drains into low-pressure chambers or vessels, CAF can be difficult to diagnose at coronary angiography. Cardiac CT better delineates the course of the tortuous vessel and can possibly show a jet into the draining cardiac chamber or vessel. Normal origins of the coronary arteries are seen and feeding vessels may also arise from bronchial or mediastinal arteries, Fig. 5.
Coronary artery vasospasm
Coronary artery vasospasm is an important cause of chest pain that can lead to myocardial infarction, ventricular arrhythmias, and sudden death . Chest pain episodes usually occur during the early morning hours. Coronary invasive angiography may or may not demonstrate fixed coronary obstruction. Often an atherosclerotic plaque at the level of vasospasm is present, and; therefore, the detection of a stenosis using cardiac CT may be crucial in interpreting the findings at invasive coronary angiography. The pathophysiology of coronary artery spasm includes endothelial dysfunction through metabolism of nitric oxide . Calcium antagonists and nitroglycerin are effective in treating and preventing new episodes of coronary spasm, Fig. 6.
Pericarditis is a common disorder, and the most common pericardial disease. It typically presents with sharp pleuritic chest pain due to irritation of the pericardium. Any type of pericardial effusion (inflammatory or hemorrhagic) may eventually result in constrictive pericarditis. Causes include post myocardial infarction (Dressler syndrome), post-surgical, after irradiation therapy, infectious, systemic diseases as rheumatoid arthritis, metabolic disorders, malignancy and idiopathic . CT is well accepted for evaluating pericarditis, although for assessment of constriction, echocardiography and MRI are more reliable. Findings include exudative or transudative, loculated fluid in the pericardial sac, in which differences in attenuation can be helpful. Thickening of the pericardial wall can be seen, and enhancement of the pericardial wall can be appreciated especially in active inflammatory pericarditis. Calcifications are seen in 50 percent of patients. Other findings include pleural effusions and ascites. It is of importance to recognize signs of constriction (Fig. 7).
Pericardial fat necrosis
Pericardial fat necrosis (PFN) is a recently recognized cause of severe chest pain . In the acute phase, the appearance of the lesion is quite similar to the so-called epiploic appendagitis (epiploic appendage fat necrosis). Although the pathogenesis of PFN is not clear, in some cases lesions have shown to be attached to the heart by a pedicle; acute torsion has been postulated as the cause of necrosis, which leads to sharp pleuritic chest pain. The appearance of the PFN depends on the age of the lesion. In the early phases, the fat composition of the lesion is well depicted. Within days, the lesion becomes smaller and denser that represents the evolution into scar tissue. PFN is included in the diagnosis of cardiophrenic mass lesions that also consider primary and secondary fat-containing neoplasms, pericardial cyst, and diaphragmatic hernia. CT demonstrates an ovoid soft tissue mass in close relation to the pericardium with low attenuation and possible adjacent thickening of the pericardium. Given the unique appearance of PFN in the initial phase at thoracic CT, it is important for the radiologist to be familiar with its features, Fig. 8.
A variety of pulmonary aetiologies can cause chest pain. Some of the common entities include pneumonia and pneumothorax, as well as pulmonary embolism. These entities typically do not cause a diagnostic challenge on routine chest CT examination, although they may be hard to interpret on plain radiographs, Fig. 9.
Chronic thromboembolic pulmonary hypertension
Acute pulmonary embolism is a frequent diagnosis associated with acute chest pain. The incidence is 70 per 100,000 per year . CT is a well-established method for diagnosing pulmonary embolism, as well as its acute complications, including right ventricular overload [20, 21]. Embolisms usually represent blood-thrombus, as a result from deep venous thrombosis, although incidentally fat- , tumour-, or air-embolisms are encountered.
Chronic thromboembolic pulmonary hypertension (CTEPH) may occur as a complication of unresolved acute pulmonary embolism. The diagnosis is often delayed due to the atypical complaints of exertional chest pain, syncope, dyspnoea, and often leads to recurrent visits to the ED without a definite diagnoses. The severity of the presenting symptoms is determined by the hemodynamic changes, thus based on the load of thrombus and obstruction. The incidence of CTEPH is about 0.1-0.5 percent of patients who survive initial acute pulmonary embolism . CT findings include those of arterial hypertension with mosaic attenuation. Moreover, additional signs include complete or partial obstruction of the pulmonary arteries, eccentric thrombus, calcified thrombus, bands, webs, and poststenotic dilatation. There are often signs of right ventricular overload (i.e., dilatation of the right ventricle, dilatation of inferior vena cava and hepatic veins). Pulmonary thromboendarterectomy is considered in symptomatic patients, Fig. 10.
Pulmonary fat embolism
Fat embolism syndrome is usually associated with traumatic or iatrogenic conditions . Although subclinical fat emboli are assumed to be present in virtually all patients with traumatic injuries, the clinical syndrome is reported to develop between 0.5 % and 2 % following fractures of the long bones. The radiological differential diagnosis includes lung contusion, pulmonary oedema, and aspiration. The association of bilateral ground glass opacities and nodular pattern in a recent traumatic context is highly suggestive of pulmonary fat embolism. Pathologic correlation is hard to find, but experimental studies show that these nodules and ground glass opacity probably represent areas of oedema, haemorrhage, and atelectasis, Fig. 11.
Intramural esophageal dissection
Intramural oesophageal dissection is a rare entity, associated with a mucosal tear, mostly developing during endoscopy or eating. The clinical presentation may greatly vary, although the diagnosis should be considered in the case of an acute onset of odynophagia during or after eating . The dissection creates a false and true lumen and may be associated with a perforation leading to pneumopericardium, pneumomediastium, or leakage to the pleural space. Complete rupture of the oesophagus (Boerhaave syndrome) or a partial tear (Mallory Weiss-tear) are among other cases of oesophageal related chest pain, and are associated with forceful emesis.
Oesophageal dissection can be treated conservatively (avoidance of oral intake). However, in cases of severe extension and an associated perforation, surgical intervention or endoscopic guided stenting should be considered, Fig. 12.
Patent ductus arteriosus
Patent ductus arteriosus (PDA) is a result of failure of the physiological mechanism that closes the fetal duct between the left pulmonary artery and the thoracic aorta after birth. Isolated PDA is estimated to account for 10-12 % of all congenital heart diseases . Presentation in adult life is rare. Clinical manifestations of PDA mainly depend on ductus size and the pressure gradient that may lead to pulmonary hypertension and consequently to chest pain. PDA can be tolerated for many years without clinical signs or symptoms, but patients may become symptomatic when associated with acquired conditions such as recurrent pneumonia or the development of chronic obstructive pulmonary disease. For adults, transcatheter occlusion of the patent ductus is the preferred treatment. The CT provides valuable pre-treatment information regarding localization, size, and shape of the duct , Fig. 13.
Cardiac CT techniques are still rapidly evolving. The newest commercially available systems image the whole heart in a single breath-hold and tube rotation, limiting effective patient radiation dose.
Dual rule-out (ECG-gated) CT, tailored to rule out aortic dissection and pulmonary embolism, as well as triple rule-out CT, additionally for ruling out significant coronary artery disease, have shown their value in the diagnostic process, also by suggesting alternative diagnoses. In the appropriate setting using the appropriate scanning protocols, a triple rule out protocol may reduce time for patient triage, radiation dose, and costs [27, 28].
The expected increase in thoracic, tailored rule-out CT examinations will urge the (general) radiologist to gain confidence in detecting and reporting alternative diagnoses on regular thoracic CT or CTA examinations requested in the setting of acute chest pain. Familiarity with some of the aortic, coronary, pericardial, and pulmonary diagnoses, and the sometimes subtle imaging findings will help to suggest alternative diagnoses, thereby avoiding diagnostic delay.
Bhuiya FA, Pitts SR, McCaig LF (2010) Emergency department visits for chest pain and abdominal pain: United States, 1999-2008. NCHS Data Brief 43:1–8
Pope JH, Aufderheide TP, Ruthazer R et al (2000) Missed diagnoses of acute cardiac ischemia in the emergency department. N Engl J Med 342:1163–1170
Voitle E, Hofmann W, Cejna M (2015) Aortic emergencies-diagnosis and treatment: a pictorial review. Insights Imaging 6:17–32
Patel HJ, Deeb GM (2008) Ascending and arch aorta: pathology, natural history, and treatment. Circulation 118:188–195
Feldman DN, Roman MJ (2006) Aneurysms of the sinuses of Valsalva. Cardiology 106:73–81
Gaibazzi N, Arruzzoli S, Beghi C (2007) Unruptured giant aneurysm of sinus of valsalva. J Am Soc Echocardiogr 20:1219–5
Kasahara H, Shimizu H, Niibori K, Yozu R (2011) Symptomatic giant aneurysms of the sinus of Valsalva. Eur J Cardiothorac Surg 39:608
Toth G, Fontos G, Andreka P (2011) Acute coronary syndrome with unexpected background: rupture of left valsalva sinus aneurysm. J Am Coll Cardiol 58:e5
Gornik HL, Creager MA (2008) Aortitis. Circulation 117:3039–3051
Katabathina VS, Restrepo CS (2012) Infectious and noninfectious aortitis: cross-sectional imaging findings. Semin Ultrasound CT MR 33:207–221
Sundaram B, Kreml R, Patel S (2010) Imaging of coronary artery anomalies. Radiol Clin N Am 48:711–727
Lee HJ, Hong YJ, Kim HY et al (2012) Anomalous origin of the right coronary artery from the left coronary sinus with an interarterial course: subtypes and clinical importance. Radiology 262:101–108
Zenooz NA, Habibi R, Mammen L, Finn JP, Gilkeson RC (2009) Coronary artery fistulas: CT findings. Radiographics 29:781–789
Canga Y, Ozcan KS, Emre A et al (2012) Coronary artery fistula: review of 54 cases from single center experience. Cardiol J 19:278–286
Stern S, de Bayes LA (2009) Coronary artery spasm: a 2009 update. Circulation 119:2531–2534
Tsujita K, Sakamoto K, Kojima S et al (2013) Coronary plaque component in patients with vasospastic angina: a virtual histology intravascular ultrasound study. Int J Cardiol 168:2411–2415
Wang ZJ, Reddy GP, Gotway MB, Yeh BM, Hetts SW, Higgins CB (2003) CT and MR imaging of pericardial disease. Radiographics 23(Spec No):S167–S180
Pineda V, Caceres J, Andreu J, Vilar J, Domingo ML (2005) Epipericardial fat necrosis: radiologic diagnosis and follow-up. AJR Am J Roentgenol 185:1234–1236
Silverstein MD, Heit JA, Mohr DN, Petterson TM, O’Fallon WM, Melton LJ (1998) Trends in the incidence of deep vein thrombosis and pulmonary embolism: a 25-year population-based study. Arch Intern Med 158:585–593
Reid JH, Murchison JT (1998) Acute right ventricular dilatation: a new helical CT sign of massive pulmonary embolism. Clin Radiol 53:694–698
van der Meer RW, Pattynama PM, van Strijen MJ et al (2005) Right ventricular dysfunction and pulmonary obstruction index at helical CT: prediction of clinical outcome during 3-month follow-up in patients with acute pulmonary embolism. Radiology 235:798–803
Fedullo PF, Auger WR, Kerr KM, Rubin LJ (2001) Chronic thromboembolic pulmonary hypertension. N Engl J Med 345:1465–1472
Yeo SH, Chang HW, Sohn SI, Cho CH, Bae KC (2013) Pulmonary and cerebral fat embolism syndrome after total knee replacement. J Clin Med Res 5:239–242
Heitmiller RF (2008) Intramural esophageal dissection with perforation. Gastroenterol Hepatol (N Y) 4:365–366
Goitein O, Fuhrman CR, Lacomis JM (2005) Incidental finding on MDCT of patent ductus arteriosus: use of CT and MRI to assess clinical importance. AJR Am J Roentgenol 184:1924–1931
Yildirim A, Karabulut N, Dogan S, Herek D (2011) Congenital thoracic arterial anomalies in adults: a CT overview. Diagn Interv Radiol 17:352–362
Halpern EJ (2009) Triple-rule-out CT angiography for evaluation of acute chest pain and possible acute coronary syndrome. Radiology 252:332–345
Ropp A, Lin CT, White CS (2015) Coronary computed tomography angiography for the assessment of acute chest pain in the emergency department: evidence, guidelines, and tips for implementation. J Thorac Imaging 30:169–175
