- Educational Review
- Open Access
Imaging findings of malignant skin tumors: radiological–pathological correlation
Insights into Imaging volume 13, Article number: 52 (2022)
Sometimes, radiologists encounter malignant skin tumors (MSTs) during image interpretation. As MSTs require different clinical management modalities for each histological subtype, accurate preoperative diagnosis is essential. The histological subtypes of MST can be easily assessed by visual inspection or biopsy. Therefore, the significant role of radiological imaging in MSTs is to evaluate the extent of local invasion, nodal involvement, and distant metastasis, and the histological estimation of MSTs by radiological imaging has not been reported until a few years ago. However, recent studies have revealed characteristic radiological features for differential diagnosis of MSTs, such as configuration, intratumoral homogeneity, signal intensity, cyst formation, and hemorrhage. Other important clinical data for determining the histological subtype of MST include age, gender, and site of occurrence. MSTs can be categorized as epidermal, melanocytic, adnexal, and mesenchymal tumors based on the origin and have distinctive characteristics. Hence, this review article was designed to describe the clinical and radiological features of MSTs.
Malignant skin tumors can be categorized as epidermal, melanocytic, adnexal, and mesenchymal tumors.
Radiological examinations play significant roles both in estimating tumor extension and in evaluating tumor characteristics.
MRI is helpful in assessing the configuration and intratumoral characteristics, such as homogeneity, signal intensity, cyst formation, and hemorrhage.
Malignant skin tumor (MST), classified into melanoma and non-melanoma, is a common type of malignancy with high incidence rates worldwide . The three most common histological subtypes include cutaneous basal cell carcinomas (cBCCs), cutaneous squamous cell carcinomas (cSCCs), and cutaneous malignant melanomas (cMMs). Skin is the largest organ of the body, covering approximately 16% of the total body weight, and is organized into two primary layers: the epidermis and dermis. The epidermis is the peripheral layer of the skin, which is composed of cornified, granular, spinous, and basal layers. The dermis underlies the epidermis and anchorages cutaneous structures, such as hair follicles, nerves, sebaceous glands, and sweat glands . cBCCs and cSCCs originate from the epidermal layer, whereas adnexal tumors occur in the dermal layer (Table 1). Mesenchymal tumors occur in the dermis or subcutaneous tissue layer.
In MSTs, MRI examinations are sometimes performed to evaluate tumor extension, including invasion depth. 18F-fluorodeoxyglucose (FDG)-positron emission tomography (PET)/CT is a useful tool for evaluating nodal and distant metastases. Previously, the prediction of histological subtypes using MRI is not required by radiologists because the MRI features of MSTs had not been reported and radiologists are unfamiliar with MSTs. Furthermore, an experienced dermatologist can easily estimate the histological subtype of MSTs by visual inspection and tissue biopsy. Although radiological investigation of MSTs has been recently published [3,4,5,6], only a few review articles have reported the MRI features of MSTs [7, 8]. Therefore, this review article was designed to describe the imaging characteristics of MSTs with emphasis on MRI features.
The prevalence and common histological subtype of MST vary according to geographical location. The number of Japanese patients with skin cancer reached 24,079 cases, accounting for 19.0 per 100,000 individuals in 2018 . Alternatively, one in five Americans will develop skin cancer by the age of 70 years. Among histological subtypes, cMMs are the most common in Western countries, whereas non-melanotic skin cancers are more common than cMMs in Asia . cBCCs and cSCCs comprise most non-melanotic skin cancers, accounting for 80–85% and 10%, respectively. Excluding cBCC, cSCC, and cMM, the remaining MSTs, including appendageal, hematolymphoid, and soft tissue tumors, account for only 2% of all MSTs .
Figure 1 shows the histological and MRI database of patients with MST in our institution. The MRI databases include primary MSTs but exclude metastatic or recurrent skin tumors. In the histological database, cSCCs and cBCCs are the most common subtypes, followed by cMMs, actinic keratosis, and Bowen’s disease. Alternatively, in the MRI database, approximately half of MSTs are SCCs. No patients with actinic keratosis and Bowen’s disease underwent MRI because they are small and precursor lesions of cSCC .
The skin is composed of three layers: the epidermis, dermis, and subcutaneous tissue . The outermost layer, the epidermis, consists of a specific constellation of cells known as keratinocytes. The middle layer, the dermis, fundamentally comprises the fibrillar structural protein known as collagen. The innermost layer, subcutaneous tissue or panniculus, contains small lobes of fat cells known as lipocytes . On radiological imaging, the epidermis and dermis are indistinguishable from each other because they exhibit nonspecific soft tissue density on CT and isointensy relative to the muscles on MRI . Skin thickness (epidermis plus dermis) varies between the different regions of the body surface; for example, the skin of the eyelid, prepuce, and inguina is the thinnest, whereas that of the back, buttock, and sole is the thickest . The subcutaneous tissue shows hypodensity on CT and hyperintensity on T1- and T2-weighted images because of its fat content .
The occurrence site is useful information to estimate the pathological diagnosis of MST. Sun exposure is a major risk factor in most MSTs, such as cBCC, cSCC, cMM with sun-exposed skin, and Merkel cell carcinoma (MCC), hence they often occur in sun-exposed areas (head and neck regions and upper extremity). Acral melanomas occur in the feet or hands. Proliferating trichilemmal tumors (PTTs) and cutaneous angiosarcomas (cASs) are often found in the scalp. Almost all cases of extramammary Paget disease (EMPD) are found in the skin of the genital or perianal area. Dermatofibrosarcoma protuberans (DFSP) is preferentially located on the trunk.
The diagnosis of MSTs using radiological examinations has limitations, because preoperative diagnosis is usually made by biopsy or visual inspection. Radiological examinations are usually performed to assess the local extent of these lesions paying particular attention to adjacent bone or deep soft tissue involvement or perineural, lymphatic, or vascular invasion is suspected, as it may alter treatment strategy. In the National Comprehensive Cancer Network guidelines, local extension of high-risk cSCC and cBCC (larger than 2 cm in the trunk or extremities and any size in the face, hands, and feet) is recommended to be evaluated by CT or MRI [16, 17]. Because of its higher sensitivity and superior soft tissue contrast, MRI is preferred over CT if perineural disease or deep soft tissue involvement is suspected . MRI is a useful tool for assessing tendon, muscle, or bone marrow invasion; in contrast, CT can reveal cortical bone invasion.
Ultrasound is helpful for assessing differential diagnosis and depth of invasion, especially in small or thin lesions less than 10 mm [19, 20]. Using very-high-frequency ultrasound, ultrasound thickness of the lesion has closely correlated with pathological thickness . Nevus can be distinguished from cutaneous lesions (BCCs or MMs) with high area under the curve values of over 0.9 .
On CT, most MSTs show non-specific soft tissue density due to its poor soft tissue contrast, and it is difficult to make an accurate diagnosis of MSTs. However, CT is sensitive in detecting calcifications, ossification, and adipose tissue. Although intratumoral fat is not observed in malignant epithelial skin tumors, it is seen in liposarcoma . Only a few MSTs are accompanied by calcification or ossification. PTTs and malignant trichilemmal tumors often have calcification , whereas cBCCs have pathological calcification in rare cases . Therefore, CT is the preferred modality to assess bone invasion, nodal metastasis, or distant metastasis.
Table 2 shows characteristics findings of MSTs. MRI provides excellent soft tissue contrast and is helpful for assessing configuration, intratumoral homogeneity, signal intensity, cyst formation, and hemorrhage. Flat elevated lesions are observed in cSCC, cMM, and cAS [3, 25]; widespread distribution in EMPD and cAS ; multiple skin lesions in MCC, cAS, and cutaneous lymphoma ; superficial depression in cSCC and cAS ; and pedunculated configuration in adnexal tumors such as porocarcinoma [27, 28]. Because MSTs often show heterogeneous signal intensity on T2-weighted images, however homogeneous signal intensity on T2-weighted images is a characteristic of cBCC, porocarcinoma, and cutaneous lymphoma [3, 28]. Intratumoral hyperintensity relative to the muscle or dermis on T1-weighted images is observed in cMM and porocarcinoma [4, 28]. Intratumoral cystic foci on T2-weighted images can be seen in cBCC and porocarcinoma. A cystic lesion with a mural nodule or wall thickening has been reported in hidradenocarcinoma and cSCC arising from an epidermoid cyst ; and hemorrhage in cAS .
Consideration of the field of view (FOV) is important for accurate diagnosis. A FOV should be narrowed as much as possible because the lesion is solitary mass in most cases, but multiple or widespread lesions can be observed on rare cases. Flat or purpura lesions, such as cAS, are usually broader than inspection; therefore, a large FOV may be necessary. Generally, the axial plane should be heavily relied on because it enables the most specific determination of the involved tissue and association with adjacent tissues . At least two planes, including axial and oblique sagittal or coronal planes, should be obtained.
The conventional MRI sequences include T1-, T2-, and fat-suppressed T2-weighted images. T1-weighted images can determine the extent of invasion into subcutaneous fat and the presence of fat or hemorrhage. T2-weighted images are usuful for evaluating the configuration and intratumoral signal intensity. Fat-suppressed T2-weighted images can detect peritumoral fat stranding and invasion of adjacent tissues. Diffusion-weighted images are limited because susceptibility artifacts occur at the air-tissue interfaces and accumulation of knowledge about apparent diffusion coefficient (ADC) of MSTs is not enough. Although the values of contrast-enhanced images are still equivocal, tumor invasion into subcutaneous fat and skull is clearly visible on contrast-enhanced images in cAS on the scalp .
Recent studies establish the advantage of high-resolution (HR) microscopy-coil MRI [32,33,34]. HR-MRI considerably improves the spatial resolution and signal-to-noise ratio. The depth of tumors measured by HR-MRI has a strong correlation with histopathological depth, and HR-MRI provides an accurate prediction of the involvement of the bone, cartilage, subcutaneous fat, or muscle [33, 34]. Although the utility of HR-MRI for diagnosing MSTs has not yet been established, HR-MRI is expected to enhance microstructural characterization such as superficial depression, tumor margins, and microcystic foci.
18F-FDG-PET/CT provides both morphologic information and data on tumor metabolic activity. 18F-FDG-PET/CT is also a useful tool for detecting nodal and distant metastases as in other malignancies; it can unmask subtle recurrences or micrometastases . A systematic review of cMMs has reported that the sensitivity of PET and PET/CT ranged from 68 to 87% and their specificity ranged from 92 to 98% in patients with stage III and IV diseases .
Malignant skin tumors
Cutaneous basal cell carcinoma (cBCC)
cBCC, which arises from keratinocytes near the basal layer, is the most common malignancy of skin cancer, and its incidence is rising . cBCC derives from the basal cell layer and outer root sheath of hair follicles . Most cBCCs occur on skin areas exposed to ultraviolet radiation from sunlight, with 75%–85% of lesions found in the head and neck regions. cBCCs most commonly occur during the seventh decade of life and affect men more frequently than women . Nodal or distant metastases are extremely rare (0.0016–0.1343%) .
Histological subtypes of cBCCs are categorized as follows: low risk (e.g., nodular, superficial, and pigmented cBCC) and high risk (morpheaform and infiltrative cBCC). Nodular BCC is the most common subtype of cBCCs and characterized by nests of basaloid cells with sharp borders. The presence of bulky mucin aggregates can produce a cystic structure .
MRI findings of nodular cBCCs in the head and neck regions show elliptical cutaneous lesions occurring mainly in the nose. These lesions have well-demarcated deep tumor margin without peritumoral fat stranding or protruding into subcutaneous tissue, with a mean maximum diameter of 23.5 mm . On T2-weighted images, they show homogeneous signal intensity accompanied by intratumoral T2-hyperintense foci (Fig. 2). Homogeneous signal intensity reflects homogeneous growth pattern without necrosis, whereas T2-hyperintense foci correspond to cystic cavities filled with mucinous contents . Routine 18F-FDG-PET/CT imaging for assessing nodal or distant metastasis is not recommended as the probability of metastasis is low in cBCCs .
Cutaneous squamous cell carcinoma (cSCC)
cSCC, which is derived from epidermal keratinocytes, is the second most common non-melanoma skin cancer after cBCC . The most significant risk factors for cSCC include sun exposure, age, and immunosuppression. cSCC affects mainly sun-exposed areas, such as the face, scalp, neck, arms, and hands . The incidence of cSCC increases with age, with an average age of onset of the mid-60 s. cSCC is more common in men than women (3:1 ratio) . The estimated incidence rates of lymph node metastasis and disease-specific death are 3.7–5.2% and 1.5–2.1%, respectively. Tumor diameter of more than 2.0 cm is the risk factor most highly associated with disease-specific death .
The histological investigation of cSCC reveals strands of atypical keratinocytes originating from the epidermis and infiltrating into the dermis or subcutaneous tissue . cSCCs range from well-differentiated SCCs, which show minimal pleomorphism and prominent keratinization, to poorly differentiated cSCCs, which show a high degree of atypia, frequent mitoses, and few keratin horn pearls .
On MRI, cSCCs show flattened lesions with a maximum diameter of 23.5–39.5 mm [3, 4]. Superficial ulcer formation, protrusion into subcutaneous tissue, ill-demarcated deep tumor margin, and peritumoral fat stranding are often observed, reflecting more aggressive behavior in cSCCs than in cBCCs . Reticular or linear hyperintensity and heterogeneous signal intensity on T2-weighted images and superficial irregular margins are observed due to a mixture of tumor cells and surrounding stroma with inflammatory cells and loose fibrosis (Fig. 3). 18F-FDG-PET/CT is recommended as clinically indicated to rule out distant metastatic disease . 18F-FDG-PET/CT has high sensitivity for detecting primary and recurrent cSCC lesions, including small cutaneous and nodal disease, which can lead to changes in management in 22–28% of all cases [6, 43]. The maximum standardized uptake value (SUVmax) of the primary cSCC is higher than in cSCC with recurrence than in cSCC without recurrence (13.0 vs. 6.4) .
Cutaneous malignant melanoma (cMM)
cMM is a malignant tumor arising from melanocytes and primarily involves the skin. cMMs can affect the eye, meninges, and various mucosal surfaces . The incidence of cMM varies greatly between countries, due to variations in racial skin phenotype. Most cMMs in northern hemisphere populations occur in sun-exposed skin areas; however, some types of cMMs occur in skin areas without sun exposure, and these tumors account for most cMMs in non-White populations . cMMs arising from sun-exposed skin areas usually occur in the head and neck, upper extremities, and trunk. Alternatively, acral melanomas, which are representative cMMs arising from sun-shielded sites, occur in the subungual area, sole of the foot, and palm of the hand [45, 47]. Although cMMs are associated with poor prognosis, the 5-year overall survival is reaching 52% in patients with cMM using nivolumab-plus-ipilimumab .
Histopathologically, the pathway of cMMs is mainly classified into two phases: radial and vertical growth phase. Radial growth phase is defined as an atypical melanocytic proliferation confined to the epidermis and superficial dermis. Vertical growth phase is a melanocytic proliferation in the dermis characterized by expansile growth (tumorigenic proliferation) and/or mitotic activity . While cMMs are usually heavily pigmented, they can also be amelanotic .
cMMs appear as flat elevated lesions with ill-defined deep tumor margins and peritumoral fat stranding, reflecting subcutaneous fat tissue invasion . Although superficial depression is rarely seen on MRI, it indicates poor prognosis due to being consistent with pathological ulceration [4, 46]. On T1-weighted images, approximately half of cMMs show hyperintensity relative to the dermis due to melanin deposition or intratumoral hemorrhage (Fig. 4). In contrast, the remaining half of cMMs shows isointensity relative to the dermis . On 18F-FDG-PET/CT, a higher SUVmax of ≥ 2.2 of primary lesions is significantly associated with recurrence [49, 50].
Porocarcinoma is a rare type of skin cancer arising from eccrine sweat glands; it is composed of poroid and cuticular cells [51, 52]. The risk factors for developing porocarcinoma are still not well understood. The most common affected site is the head and neck, followed by the lower extremity . The mean age is 67.5 years without gender predilection. Masses and nodules are the most common modes of presentation . Metastases occur at presentation in 31% of all cases; the most common metastasized sites are the nearby lymph nodes (58%), followed by the lung (13%) [51, 52].
Histopathologically, porocarcinoma evolves from a preexisting poroma, which is the benign counterpart of porocarcinoma; however, it can also develop de novo . Several histological features include ductal differentiation, nests of basaloid cells, nuclear pleomorphism, and atypical mitoses [51, 52].
On MRI, porocarcinomas usually appear as pedunculated solid masses; meanwhile, in rare instances, porocarcinomas appear as subcutaneous cystic masses. The mean maximum diameter and height of solid masses are 36 mm and 12 mm, respectively . Moreover, well-demarcated tumor margins and smooth skin surfaces are observed. On T2-weighted images, solid components demonstrate mild hyperintensity relative to the muscle, accompanied by hyperintense foci filed with fluid contents due to ductal differentiation (Fig. 5). On T1-weighted images, intratumoral hyperintensity relative to the muscle is observed, reflecting richly vascular stoma with dilated vessels .
Hidradenocarcinoma is a rare malignant adnexal tumor arising from the sweat glands, constituting the malignant counterpart of hidradenomas [53, 54]. Hidradenocarcinomas occur most frequently on the head and neck region, especially on the face . Lesions are solitary, varying in size ranging from 1 to 6 cm . There is a slight male predominance; it occurs most often in the fifth to the seventh decades of life. Nodal and visceral metastases occur in 39% and 28% of all cases, respectively. The recurrence rate is as high as 50%, and the 5-year postsurgical survival rate is less than 30% .
Tumors arise conventionally de novo, or the carcinoma might occur due to the overgrowth of the benign precursor lesion. Hidradenocarcinomas are composed of the same cell types as in hidradenomas, including predominantly clear cells, squamoid cells, and mucinous cells . Malignant cells show nuclear pleomorphism, necrosis, and increased mitotic activity .
The characteristic imaging features of hidradenocarcinomas are not yet determined. Based on previous case reports, hidradenocarcinomas are radiologically classified into two patterns: cystic lesions with mural nodules or solid lesions with cystic components [29, 55]. The former shows a well-circumscribed oval mass attached to the dermis. Hyperintensity or hypointensity of internal fluid contents relative to the muscle on T1-weighted images is caused by hemorrhage or necrotic mucoid fluid. Mural nodules show prominent enhancement on contrast-enhanced T1-weighted images [29, 55]. The latter appears as a subcutaneous solid mass with heterogeneous signal intensity, reflecting cysts or necrosis  (Fig. 6). The size of the cysts varies from small to large.
Extramammaly Paget disease (EMPD)
EMPD is a rare cutaneous malignancy, presenting as a primary intraepithelial adenocarcinoma. EMPD commonly occurs on apocrine-rich skin including Paget cells and usually affects the skin of the genital or perianal area [57, 58]. EMPD usually occurs between the ages of 50 and 80 years, with a peak incidence at the age of 65 years, with a male predilection in Asian populations [26, 58]. EMPD often presents with a slowly enlarging, asymmetrical, white and red, scaly plaque. Patients with EMPD have a good prognosis with a 5-year overall survival rate of 75–95% .
Histopathologically, EMPD is characterized by intradermal proliferation of Paget cells. Typical findings include large round Paget cells singly or in nests, distributed throughout the epidermis . Paget cells are concentrated in the lower epidermis but can scatter higher. They mainly spread horizontally; however, in advanced stages, invasion is deeper. Moreover, invasion into the dermis, subcutaneous tissue, blood vessels, and lymphatic vessels is observed [26, 58].
On MRI, EMPDs are demonstrated as horizontally widespread skin thickness due to spreading Paget cells along the epidermis and dermis. T1- and T2-weighted images show nonspecific hypointensity (Fig. 7). Marked enhancement on gadolinium-enhanced T1-weighted images . A good correlation in vertical and horizontal ranges of tumor extension between histological examination and gadolinium-enhanced T1-weighted images has been reported . On 18F-FDG-PET/CT, thick lesions (> 1.0 cm) show intense FDG uptake (SUVmax, 7.5–14.9), whereas thin lesions (< 1.0 cm) show mild FDG uptake (SUVmax, 3.0–4.0) .
Proliferating trichilemmal tumor (PTT)
PTT is a solid-cystic neoplasm with predominant outer root sheath differentiation at the isthmus . PTT originates from the external root of hair follicles and occurs preferentially in areas with dense hair follicle concentration; therefore, PTTs usually affect the scalp, accounting for 85%. Patient ages range from 21 to 88 years, with a mean age of 62.4 years . The ratio of males to females is 1:4. PTT usually appears as a solitary, slow-growing, and exophytic lesion with a size of 2–25 cm. Some lesions show rapid growth of a previously existing asymptomatic lesion . The morphological spectrum includes benign, atypical (intermediate), and rare malignant lesions . The rates of local recurrence and regional lymph node metastasis are 3.7% and 1.2%, respectively .
PTT occurs either de novo or from an existing trichilemmal cyst, the benign counterpart of PTT. PTT appears as a well-circumscribed solid and cystic neoplasms involving the dermis and sometimes extending to the subcutaneous tissue. Intratumoral calcification, ample eosinophilic cytoplasm, and keratinization without a granular layer (trichilemmal keratinization) are often observed .
The configuration of PTT is typically oval/round shape. On CT, PTTs show soft tissue density masses and are often associated with intratumoral calcification and hyperdense areas, which reflect a characteristic histological finding of trichilemmal keratinization with dystrophic calcification and abundant cholesterol crystals . On T2-weighted images, they show heterogeneous signal intensity with intratumoral hypointense areas relative to the gray matter, which corresponds to a layered and aggregated keratin debris  (Fig. 8). Marked restricted diffusion is not usually observed with a relatively high ADC value of 1.49 ± 0.24 × 10−3 mm2/s) .
Sebaceous carcinoma (SC)
SC is a rare and potentially aggressive cutaneous malignancy arising from sebaceous glands . Areas with particularly high-density sebaceous glands (i.e., eyelids, face, scalp, and neck) have a higher incidence of SC. SCs most commonly occur in the periorbital region . SCs primarily affect elderly individuals, with a median age of 72 years. Men and women are affected equally. The most common presentation of periorbital SC is a painless subcutaneous nodule of the eyelid. The rate of regional nodal involvement in ocular SC may be as high as 10%–28%. Distant metastasis is uncommon; however, cases with metastasis to the lung, liver, bone, and brain have been reported [63, 64].
Histopathologically, sebaceous glands with variable degrees of differentiation and atypia are observed. Growth patterns may be lobular, focal necrosis, papillary, or mixed. SC demonstrates a basaloid neoplasm in lobules or sheets of cells separated by a fibrovascular stroma with infiltrating edges . Lipid granules are present in the cytoplasm of cells and are positive for oil red O stain.
Detailed imaging findings of SCs have not been reported. SCs show either a pedunculated or invasive mass. In the eyelid, they show small elevated nodules in the early stage and invade into the orbit as the disease progresses [65, 66]. Slight hypodensity relative to the muscle on CT and hyperintensity on both T1- and T2-weighted images may be seen because the lesion contains lipid materials (Fig. 9).
Merkel cell carcinoma (MCC)
MCC is an aggressive neoplasm defined as a primary neuroendocrine carcinoma of the skin . Most MCCs are driven by Merkel cell polyomavirus, and the reminding MCCs are associated with exposure to ultraviolet light . Most tumors are located in the head and neck (48%), followed by the upper extremity (25%) . MCC tends to affect men more than women at a rate of 2:1, commonly occurring in individuals older than 50 years . The typical clinical presentation of MCCs is an erythematous or violaceous nodule on sun-exposed areas . The most clinically relevant prognostic factors include tumor size and the presence of regional or distant metastasis . The 5-year overall survival is approximately 51% for local disease, 35% for nodal disease, and 14% for distant disease .
Histopathologically, MCCs are typically characterized as dermal tumors with sheets and nests of small round cells. Numerous mitotic figures and necrotic cells are commonly observed . Because of high cellularity, small round cell tumors, such as blastic lymphomas, should be considered in the differential diagnosis .
Common imaging features of primary MCCs include cutaneous or subcutaneous nodules and focal or diffuse skin thickening . Moreover, MCCs appear as perifascial muscular or intramuscular metastases . Necrosis is common, whereas calcifications are unseen. On MRI, MCCs exhibit hypo- to isointensity on T1-weighted images and iso- to hyperintensity on T2-weighted images reflecting the high cellularity of small round cell tumors  (Fig. 10). Differential diagnosis includes cutaneous or soft tissue lymphoma owing to the increased cellularity. They show a low ADC value due to high cellular density. The mean SUVmax of 18F-FDG-PET for primary MCCs ranges from 4 to 6.5 .
Cutaneous angiosarcoma (cAS)
cAS are a family of aggressive malignancies demonstrating vascular endothelial cell differentiation . Their etiology is still unknown in most cases, although few cASs arise after radiation exposure or long-standing lymphedema as a part of Stewart–Treves syndrome . The head and neck region is the most common location of cASs, with the scalp alone accounting for more than 60% of cases . The estimated male-to-female ratio is approximately 3:1, with its incidence peaking in the seventh decade of life. cASs on the scalp typically present with an enlarging bruise-like purpura and may be associated with ulceration and/or mass formation . The prognosis for cAS is poor, with a 5-year survival rate of less than 40%. Prognostic factors associated with poor survival are older age, worse performance status, larger tumor size, and the scalp as the site of the primary lesion .
Macroscopically, cASs are typically hemorrhagic with areas of focal necrosis or cystic degeneration. cASs range from well-formed, anastomosing vessels to solid sheets of high-grade epithelioid or spindle cells and high-grade morphology, with variable nuclear atypia, mitotic activity, and coagulative necrosis .
On images, cASs on the scalp show the wide-ranging appearance of single or multiple lesions [25, 31]. MRI shows flattened configuration, reflecting horizontal extension, with a maximum diameter and diameter-to-height ratio of 34.9 mm and 3.3, respectively. They usually appear as flattened elevated lesions with an obtuse angle, invading the subcutaneous tissue and muscles. Intratumoral hypointensity and mixed hyper- and hypointensity on T2-weighted images are characteristic features of cASs due to intratumoral hemorrhage and hemosiderin deposition  (Fig. 11). On 18F-FDG-PET/CT, primary tumors with high SUVmax values (> 7.96) show significantly poorer prognosis than those with low SUVmax values .
Dermatofibrosarcoma protuberans (DFSP)
DFSP is a relatively usual, locally aggressive cutaneous mesenchymal tumor, characterized by a high rate of local recurrence, but minimal risk of metastasis. DFSP is preferentially located on the trunk, accounting for 40–50%, followed by the proximal portion of the limbs, accounting for 30–40% . It is most commonly found between the second and fifth decades of life, with a male-to female ratio of approximately 3:2. The overall survival rate of DFSP is high, ranging between 91 and 100% [73, 74].
Histopathologically, DFSP shows a poorly invading the full thickness of the dermis and extending into the subcutaneous tissue. The infiltration of tumor cells into the subcutaneous fat has been demonstrated as a honeycomb pattern. Microscopically, DFSP is characterized by a uniform population of spindle-shaped fibroblasts with long nuclei, intercellular collagen, dilated vascular space, and small capillaries [74, 75].
On images, DFSPs appear as oval and well-defined masses, but are rarely ill-defined because of the permeative infiltration into subcutaneous fat . The diameter of the lesions ranges from 2 to 17 cm (mean 5.6 cm) . DFSPs appear as isointense superficial nodules or masses relative to the muscle on T1-weighted images and show predominant hyperintensity on T2-weighted images owing to the presence of myxoid degeneration. However, they also show intermediate to low signal intensity on T2-weighted images due to various amounts of fibrous tissue (Fig. 12). On contrast-enhanced T1-weighted images, intermediate or marked degree of homogeneous or heterogeneous enhancement is observed due to the hypervascularity [74, 76].
Mycosis fungoides (MF)
MF is the most common subtype of cutaneous T-cell lymphoma (CTCL), accounting for 60% of all CTCLs, and comprises almost half of all primary cutaneous lymphomas . Associations with long-term exposure to various allergens and associations with chronic skin disorders have also been suggested as possible etiological factors. Common sites include the upper thigh and groin, breasts, armpits, and the crook of the elbow. Most patients are adults/elderly; however, the disease can also occur in children and adolescents, with a 2:1 male-to-female ratio . In the early stage, the lesions are often confined to sun-protected areas and show patches or erythematous plaques. Patients with advanced-stage MF characteristically present with a combination of patches, plaques, and tumors, which often show ulceration . Although the 5-year survival rate of patients with early disease (stage IA–IIA) is 78–94%, that of patients with advanced disease (stage IIIB–IVB) is less than or equal to 40% .
Histopathologically, early patch lesions show superficial band-like or lichenoid infiltrates, mainly consisting of lymphocytes and histiocytes. With progression to the tumor stage, the tumor cells increase in number and size, showing variable proportions of small, medium, and large cerebriform cells. The infiltration of these cells becomes more diffuse in the dermis and subcutaneous tissue .
On images, in the early stage, MFs show no abnormality or slight degree of cutaneous thickening. In the stage with tumor formation, diffuse thickening or mass formation in the skin is observed, sometimes associated with an ulcer. On T2-weighted images, MFs show homogeneous intermediate signal intensity, reflecting their high cellularity (Fig. 13). Diffuse marked enhancement on contrast-enhanced images and marked restricted diffusion on diffusion-weighted images are observed [80, 81].
Radiological investigation of MSTs is essential for evaluating tumor extension, nodal involvement, and distant metastasis. Although considering the differential diagnosis of MSTs is still challenging for radiologists, we believe that MRI can play a supplementary role for determining the histological subtypes of MSTs.
Availability of data and materials
Data sharing is not applicable. Because this article has no datasets that were constituted or analyzed during the current study.
Apparent diffusion coefficient
Cutaneous basal cell carcinoma
Cutaneous malignant melanoma
Cutaneous squamous cell carcinoma
Extramammary Paget disease
Merkel cell carcinoma
Magnetic resonance imaging
Malignant skin tumor
Positron emission tomography
Proliferating trichilemmal tumor
Maximum standardized uptake value
Ciążyńska M, Kamińska-Winciorek G, Lange D et al (2021) The incidence and clinical analysis of non-melanoma skin cancer. Sci Rep 11:4337
Simões MCF, Sousa JJS, Pais A (2015) Skin cancer and new treatment perspectives: a review. Cancer Lett 357:8–42
Kawaguchi M, Kato H, Tomita H et al (2020) Magnetic resonance imaging findings differentiating cutaneous basal cell carcinoma from squamous cell carcinoma in the head and neck region. Korean J Radiol 21:325–331
Kawaguchi M, Kato H, Tomita H et al (2020) MR imaging findings for differentiating cutaneous malignant melanoma from squamous cell carcinoma. Eur J Radiol 132:109212
Akaike G, Akaike T, Fadl SA, Lachance K, Nghiem P, Behnia F (2019) Imaging of merkel cell carcinoma: what imaging experts should know. Radiographics 39:2069–2084
Mahajan S, Barker CA, Singh B, Pandit-Taskar N (2019) Clinical value of 18F-FDG-PET/CT in staging cutaneous squamous cell carcinoma. Nucl Med Commun 40:744–751
Juan YH, Saboo SS, Tirumani SH et al (2014) Malignant skin and subcutaneous neoplasms in adults: multimodality imaging with CT, MRI, and 18F-FDG PET/CT. AJR Am J Roentgenol 202:W422-438
Kim JH, Kim JY, Chun KA, Jee WH, Sung MS (2008) MR imaging manifestations of skin tumors. Eur Radiol 18:2652–2661
Coggshall K, Tello TL, North JP, Yu SS (2018) Merkel cell carcinoma: an update and review: pathogenesis, diagnosis, and staging. J Am Acad Dermatol 78:433–442
Niino M, Matsuda T (2019) International comparison of skin cancers incidence by detailed sites. Jpn J Clin Oncol 49:1176–1177
Holterhues C, Vries E, Louwman MW, Koljenović S, Nijsten T (2010) Incidence and trends of cutaneous malignancies in the Netherlands, 1989–2005. J Invest Dermatol 130:1807–1812
Fernandez Figueras MT (2017) From actinic keratosis to squamous cell carcinoma: pathophysiology revisited. J Eur Acad Dermatol Venereol 31(Suppl 2):5–7
Kolarsick PAJ, Kolarsick MA, Goodwin C (2011) Anatomy and physiology of the skin. J Dermat Nurses’ Assoc 3:203–213
Kawaguchi M, Kato H, Matsuo M (2019) CT and MRI features of scalp lesions. Radiol Med 124:1049–1061
Lee Y, Hwang K (2002) Skin thickness of Korean adults. Surg Radiol Anat 24:183–189
National Comprehensive Cancer Network. Basal Cell Skin Cancer. Accessed January 24, 2022.
National Comprehensive Cancer Network. Squamous Cell Skin Cancer. Accessed January 24, 2022.
Anderson SE, Beer KT, Banic A et al (2005) MRI of merkel cell carcinoma: histologic correlation and review of the literature. AJR Am J Roentgenol 185:1441–1448
Botar-Jid CM, Cosgarea R, Bolboacă SD et al (2016) Assessment of cutaneous melanoma by use of very- high-frequency ultrasound and real-time elastography. AJR Am J Roentgenol 206:699–704
Andrėkutė K, Linkevičiūtė G, Raišutis R, Valiukevičienė S, Makštienė J (2016) Automatic differential diagnosis of melanocytic skin tumors using ultrasound data. Ultrasound Med Biol 42:2834–2843
Marosán-Vilimszky P, Szalai K, Horváth A, et al. (2021) Automated Skin Lesion Classification on Ultrasound Images. Diagnostics (Basel) 11.
Zhang J, Li Y, Zhao Y, Qiao J (2018) CT and MRI of superficial solid tumors. Quant Imaging Med Surg 8:232–251
Kawaguchi M, Kato H, Suzui N, et al. (2021) Imaging findings of trichilemmal cyst and proliferating trichilemmal tumour. Neuroradiol J:19714009211017789.
Forouzan P, Calame A, Uebelhoer NS, Cohen PR (2021) Basal cell carcinoma with calcification: case report of calcifying basal cell carcinoma and review of calcinosis cutis associated with basal cell carcinoma. Cureus 13:e12721
Kawaguchi M, Kato H, Suzui N et al (2021) Imaging findings of cutaneous angiosarcoma of the scalp: comparison with cutaneous squamous cell carcinoma. Neuroradiol J 34:329–334
Akaike G, Nozaki T, Matsusako M et al (2013) Magnetic resonance imaging for extramammary Paget’s disease: radiological and pathological correlations. Skeletal Radiol 42:437–442
Arai M, Nozaki T, Matsusako M et al (2020) MR imaging of mushroom-like skin adnexal tumors in the scalp: a report of two cases. Magn Reson Med Sci 19:282–285
Kawaguchi M, Kato H, Imada H et al (2021) Magnetic resonance imaging characteristics of poroma and porocarcinoma. J Comput Assist Tomogr 45:447–451
Ngo N, Susa M, Nakagawa T et al (2018) Malignant transformation of nodular hidradenoma in the lower leg. Case Rep Oncol 11:298–304
Manaster BJ (2013) Soft-tissue masses: optimal imaging protocol and reporting. AJR Am J Roentgenol 201:505–514
Isoda H, Imai M, Inagawa S, Miura K, Sakahara H (2005) Magnetic resonance imaging findings of angiosarcoma of the scalp. J Comput Assist Tomogr 29:858–862
Budak MJ, Weir-McCall JR, Yeap PM et al (2015) High-resolution microscopy-coil MR imaging of skin tumors: techniques and novel clinical applications. Radiographics 35:1077–1090
Sheng M, Tang M, Lin W et al (2021) The value of preoperative high-resolution MRI with microscopy coil for facial nonmelanoma skin cancers. Skin Res Technol 27:62–69
Dobbs NW, Budak MJ, White RD, Zealley IA (2020) MR-Eye: high-resolution microscopy coil MRI for the assessment of the orbit and periorbital structures, part 1: technique and anatomy. AJNR Am J Neuroradiol 41:947–950
Schröer-Günther MA, Wolff RF, Westwood ME et al (2012) F-18-fluoro-2-deoxyglucose positron emission tomography (PET) and PET/computed tomography imaging in primary staging of patients with malignant melanoma: a systematic review. Syst Rev 1:62
Kim DP, Kus KJB, Ruiz E (2019) Basal cell carcinoma review. Hematol Oncol Clin North Am 33:13–24
Fania L, Didona D, Morese R et al (2020) Basal cell carcinoma: from pathophysiology to novel therapeutic approaches. Biomedicines 8:449
Nguyen-Nielsen M, Wang L, Pedersen L et al (2015) The incidence of metastatic basal cell carcinoma (mBCC) in Denmark, 1997–2010. Eur J Dermatol 25:463–468
Thway K, Billings S (2020) Angiosarcoma. WHO classification of Soft tissue and Bone Tumors 5th Lyon, France: IARC Press 3:176–178.
Motaparthi K, Kapil JP, Velazquez EF (2017) Cutaneous squamous cell carcinoma: review of the eighth edition of the american joint committee on cancer staging guidelines, prognostic factors, and histopathologic variants. Adv Anat Pathol 24:171–194
Que SKT, Zwald FO, Schmults CD (2018) Cutaneous squamous cell carcinoma: Incidence, risk factors, diagnosis, and staging. J Am Acad Dermatol 78:237–247
Stratigos A, Garbe C, Lebbe C et al (2015) Diagnosis and treatment of invasive squamous cell carcinoma of the skin: European consensus-based interdisciplinary guideline. Eur J Cancer 51:1989–2007
Mahajan S, Barker CA, Mauguen A, Singh B, Pandit-Taskar N (2020) Restaging [(18)F] fludeoxyglucose positron emission tomography/computed tomography scan in recurrent cutaneous squamous cell carcinoma: diagnostic performance and prognostic significance. J Am Acad Dermatol 82:878–886
Kawaguchi M, Kato H, Matsuyama K, Noda Y, Hyodo F, Matsuo M (2022) Prognostic value of (18)F-FDG PET/CT and MRI features in patients with high-risk and very-high-risk cutaneous squamous cell carcinoma. Br J Radiol:20211003.
Garbe C, Amaral T, Peris K et al (2020) European consensus-based interdisciplinary guideline for melanoma. Part 1: Diagnostics - Update 2019. Eur J Cancer 126:141–158
Elder DE, Lazar AJ, Barnhil RL, et al. (2018) Melanocytic tumours. WHO classification of Skin Tumors 4 Lyon, France: IARC Press:66–71.
Leonardi GC, Falzone L, Salemi R et al (2018) Cutaneous melanoma: from pathogenesis to therapy (Review). Int J Oncol 52:1071–1080
Larkin J, Chiarion-Sileni V, Gonzalez R et al (2019) Five-year survival with combined nivolumab and ipilimumab in advanced melanoma. N Engl J Med 381:1535–1546
Son SH, Kang SM, Jeong SY et al (2016) Prognostic value of volumetric parameters measured by pretreatment 18F FDG PET/CT in patients with cutaneous malignant melanoma. Clin Nucl Med 41:e266-273
Kang S, Ahn BC, Hong CM et al (2011) Can (18)F-FDG PET/CT predict recurrence in patients with cutaneous malignant melanoma? Nuklearmedizin 50:116–121
Salih AM, Kakamad FH, Baba HO et al (2017) Porocarcinoma; presentation and management, a meta-analysis of 453 cases. Ann Med Surg (Lond) 20:74–79
Kazakov DV, Requena L, Argeyi ZB, et al. (2018) Porocarcinoma. WHO classification of Skin Tumors 4 Lyon, France: IARC Press:159–160.
Soni A, Bansal N, Kaushal V, Chauhan AK (2015) Current management approach to hidradenocarcinoma: a comprehensive review of the literature. Ecancermedicalscience 9:517
Kazakov DV, Argeyi ZB, Brenn T, et al. (2018) Hidradenocarcinoma. WHO classification of Skin Tumors 4 Lyon, France: IARC Press:164–165.
An JK, Woo JJ, Hong YO (2019) Malignant sweat gland tumor of breast arising in pre-existing benign tumor: a case report. World J Clin Cases 7:3033–3038
Moore JA, Cui S, Berger N et al (2021) Hidradenocarcinoma: a rare but challenging diagnosis. Clin Imaging 75:138–142
Bayan CY, Khanna T, Rotemberg V, Samie FH, Zeitouni NC (2018) A review of non-invasive imaging in extramammary Paget’s disease. J Eur Acad Dermatol Venereol 32:1862–1873
Morris CR, Hurst EA (2020) Extramammary paget disease: a review of the literature-part I: history, epidemiology, pathogenesis, presentation, histopathology, and diagnostic work-up. Dermatol Surg 46:151–158
Morris CR, Hurst EA (2020) Extramammary paget’s disease: a review of the literature Part II: treatment and prognosis. Dermatol Surg 46:305–311
Tian Y, Wu HB, Li DL, Li HS, Zhou WL, Wang QS (2015) Utility of 18F-FDG PET/CT in the diagnosis and staging of extramammary Paget’s disease. Nucl Med Commun 36:892–897
Requena L, Crowson AN, Kaddu S, Kazakov DV, Michal M (2018) Proliferating trichilemmal tumor. WHO classification of Skin Tumors 4 Lyon, France: IARC Press:196–197.
Ye J, Nappi O, Swanson PE, Patterson JW, Wick MR (2004) Proliferating pilar tumors: a clinicopathologic study of 76 cases with a proposal for definition of benign and malignant variants. Am J Clin Pathol 122:566–574
Knackstedt T, Samie FH (2017) Sebaceous carcinoma: a review of the scientific literature. Curr Treat Options Oncol 18:47
Kyllo RL, Brady KL, Hurst EA (2015) Sebaceous carcinoma: review of the literature. Dermatol Surg 41:1–15
Sekgololo J, Chauke R, Tshazi N (2020) A rare giant extraocular, anterior chest wall sebaceous carcinoma. Int J Surg Case Rep 66:110–114
Zhao X, Wang GF, Zhao K, Cui HG, Ding W (2015) Value of (18)F-FDG-PET/CT in ocular sebaceous adenocarcinoma: a case report and literature review. Int J Clin Exp Med 8:19524–19529
Kervarrec T, Samimi M, Guyétant S et al (2019) Histogenesis of merkel cell carcinoma: a comprehensive review. Front Oncol 9:451
Harms PW, Harms KL, Moore PS et al (2018) The biology and treatment of Merkel cell carcinoma: current understanding and research priorities. Nat Rev Clin Oncol 15:763–776
Smith VA, Camp ER, Lentsch EJ (2012) Merkel cell carcinoma: identification of prognostic factors unique to tumors located in the head and neck based on analysis of SEER data. Laryngoscope 122:1283–1290
Lee KC, Chuang SK, Philipone EM, Peters SM (2019) Characteristics and prognosis of primary head and neck angiosarcomas: a surveillance, epidemiology, and end results program (SEER) analysis of 1250 cases. Head Neck Pathol 13:378–385
Fujisawa Y, Yoshino K, Fujimura T et al (2018) Cutaneous angiosarcoma: the possibility of new treatment options especially for patients with large primary tumor. Front Oncol 8:46
Umemura H, Yamasaki O, Kaji T et al (2017) Prognostic value of (18) F-fluorodeoxyglucose positron emission tomography/computed tomography in patients with cutaneous angiosarcoma: A retrospective study of 18 cases. J Dermatol 44:1046–1049
Llombart B, Serra-Guillén C, Monteagudo C, López Guerrero JA, Sanmartín O (2013) Dermatofibrosarcoma protuberans: a comprehensive review and update on diagnosis and management. Semin Diagn Pathol 30:13–28
Mujtaba B, Wang F, Taher A et al (2021) Dermatofibrosarcoma protuberans: pathological and imaging review. Curr Probl Diagn Radiol 50:236–240
Llombart B, Serra C, Requena C et al (2018) Guidelines for diagnosis and treatment of cutaneous sarcomas: dermatofibrosarcoma protuberans. Actas Dermosifiliogr (Engl Ed) 109:868–877
Zhang L, Liu QY, Cao Y, Zhong JS, Zhang WD (2015) Dermatofibrosarcoma protuberans: computed tomography and magnetic resonance imaging findings. Medicine (Baltimore) 94:e1001
Willemze R, Cerroni L, Kempf W et al (2019) The 2018 update of the WHO-EORTC classification for primary cutaneous lymphomas. Blood 133:1703–1714
Carroni L, Sander CA, Smoller BR, Willemze R (2018) Mycosis fungoides. WHO classification of Skin Tumors 4 Lyon, France: IARC Press 226–230
Agar NS, Wedgeworth E, Crichton S et al (2010) Survival outcomes and prognostic factors in mycosis fungoides/Sézary syndrome: validation of the revised International Society for Cutaneous Lymphomas/European Organisation for Research and Treatment of Cancer staging proposal. J Clin Oncol 28:4730–4739
Lee HJ, Im JG, Goo JM et al (2003) Peripheral T-cell lymphoma: spectrum of imaging findings with clinical and pathologic features. Radiographics 23:7–26
Lim CY, Ong KO (2013) Imaging of musculoskeletal lymphoma. Cancer Imaging 13:448–457
Ethics approval and consent to participate
Consent for publication
The authors declare that they have no competing interests.
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
About this article
Cite this article
Kawaguchi, M., Kato, H., Noda, Y. et al. Imaging findings of malignant skin tumors: radiological–pathological correlation. Insights Imaging 13, 52 (2022). https://doi.org/10.1186/s13244-022-01205-8
- Skin neoplasms
- Magnetic resonance imaging
- Positron emission tomography
- Computed tomography
