Pancreas transplantation is a surgical treatment for diabetes mellitus. More than 23,000 pancreas transplants have now been reported to the International Transplant Registry (IPTR). Early diagnosis and therapy for graft-related complications are essential for graft survival. Radiologists must therefore understand the surgical procedure and the potential complications. During the course of this review, we will illustrate the normal post-operative anatomy and the imaging appearances of common potential complications.
Pancreas transplantation is a surgical treatment for diabetes mellitus (DM). Most recipients have type 1 DM but 7.7% have type 2 DM [1, 2]. Transplant obviates the need for insulin treatment and is associated with an improvement in quality of life and life expectancy. The euglycaemia obtained has been shown to prevent and sometimes improve the secondary complications of DM including nephropathy, neuropathy, retinopathy and macrovascular disease.
The first whole-pancreas transplant was performed in the University of Minnesota, USA in 1966  and, with improvements in surgical technique and immunosuppressive therapy, increasing numbers of successful transplants are performed. More than 23,000 pancreas transplants have now been reported to the International Transplant Registry (IPTR) . In the UK the number of pancreas transplants has steadily increased from 30, in 1998-1999, to 209, in 2007-2008.
Following pancreas transplantation, it is essential that any graft-related complications are diagnosed early to ensure prompt treatment and optimal survival of both graft and patient. In order to successfully interpret the imaging, it is essential that the surgical procedure, normal post-operative appearances and potential complications are understood by the reporting radiologists. The clinically suspected complication should direct the imaging modality to be employed. In particular, the most appropriate CT protocols should be utilised to ensure that the maximum information is obtained at the lowest possible radiation dose. Within this review we will illustrate the normal post-operative anatomy and the imaging appearances of the commonest potential complications.
Types of pancreas transplant
Pancreas transplantation is most commonly performed in conjunction with a kidney transplant, a procedure referred to as simultaneous pancreas-kidney (SPK) transplantation. SPK transplants are considered in patients with insulin-dependent DM and chronic renal failure either requiring or imminently requiring dialysis. SPK recipients have improved 10-year survival when compared with diabetic patients receiving kidney transplantation alone: mean 23.4 years versus 12.9 years, respectively .
Of 209 pancreas transplants performed in the UK in 2007-2008, 173 (83%) were SPK transplants donated following brain death (DBD), although an increasing number of pancreases in the UK are donated following cardiac death (DCD). Alternatively, solitary pancreas transplants may be performed , usually in patients who have already had a kidney transplant often from a living donor: so-called pancreas after kidney transplants (PAK). Approximately 10% of cases involve PAKs. Occasionally, both organs (distal pancreas segment and whole kidney) may come from a living donor . Only 0.5% pancreatic transplants are from living donors .
Less than 10% involve pancreas transplantation alone (PTA). Thirty percent of those given a PTA will eventually need a renal transplant because of the adverse cumulative effects of immunosuppression with calcineurin inhibitors . PTA is performed for patients with labile, poorly controlled insulin-dependent type 1 DM with stable renal function. The principal indication for a PTA is life-threatening hypoglycaemic unawareness. The long-term advantages of good glycaemic control must be weighed against the risks of major surgery and the complications of long-term immunosuppressive therapy.
At our institution, the pancreas transplant is placed intra-peritoneally, lying on the right side of the pelvis; the kidney is placed in the left iliac fossa and is extra peritoneal to facilitate biopsy (Fig. 1).
The donor pancreas is retrieved en bloc with the duodenum, which is transected and stapled proximally just beyond the pylorus and distally in the third part of the duodenum. The common bile duct is also divided and ligated at the level of the duodenum. At the recipient hospital the donor iliac artery bifurcation is anastomosed to the stumps of the splenic and superior mesenteric arteries of the pancreas bloc; this facilitates implantation, during which the donor common iliac artery is anastomosed to the recipient artery, usually the common iliac in our centre; thus the donor iliac artery forms an inverted Y-graft conduit.
Venous outflow is via the donor portal vein, which is anastomosed end-to-side to the recipient inferior vena cava; in some centres the pancreas is implanted to the external iliac vessels, in which case the portal vein may need to be extended by anastomosing donor iliac vein to act as a conduit. However, the use of venous extension grafts increases the risk of graft thrombosis. A modification to this technique is portal rather than systemic venous drainage of the endocrine pancreas by anastomosing the portal vein to the superior mesenteric vein.
Exocrine secretions drain via the donor duodenum, which is nowadays commonly anastomosed to recipient small bowel, either directly or, as in our centre, to a Roux loop of recipient jejunum via a side-to-side anastomosis. Alternatively, the donor duodenum may be anastomosed directly to the bladder . In all modifications the recipient’s native pancreas is left untouched.
When both organs come from a living donor a distal pancreatectomy is performed. The pancreas is divided at the neck. Distally the main trunks of the splenic artery and vein are divided proximal to the splenic branches. Proximally the splenic artery is divided at its origin off the coeliac trunk and the splenic vein is divided at the confluence with the superior mesenteric vein. The donor splenic artery is then anastomosed end to side to a recipient iliac artery and the donor splenic vein is anastomosed end to side to a recipient iliac vein. Exocrine secretions drain via an enteric route or the bladder [6, 9, 10].
Imaging techniques and normal anatomy
Ultrasound (US), computed tomography (CT) and magnetic resonance imaging (MRI) are all used to assess the pancreas following transplantation. Conventional angiography is largely reserved to confirm vascular complications and permits endovascular therapy.
US is of limited value in the initial assessment of the pancreatic parenchyma, as the transplant margins are often poorly defined. In addition, views may be limited by overlying bowel gas due to the intra-peritoneal position of the transplant pancreas. Assuming good views are obtained, Doppler US may be of great use in evaluating the patency and calibre of the arterial and venous grafts (Fig. 2). The resistive index has been shown to be an unreliable indicator of rejection and therefore biopsy is the diagnostic “gold standard” [11, 12]. US-guided biopsies have a high success rate , ensuring the modality’s continued application in this field. There is, however, an increased risk of bleeding associated with pancreas biopsy compared with transplant kidney biopsy as the pancreas is intraperitoneal, thus bleeding will not be tamponaded by either the peritoneum or by the organ capsule. Pancreatic leaks are the other complication which deters clinicians, and for these reasons biopsy of the renal transplant may be used as a surrogate marker for pancreatic rejection , although asynchronous rejection may occur.
Complete and reliable evaluation of the pancreatic parenchyma and the vascular and enteric anastomoses is best achieved with cross-sectional imaging. Both CT and MRI have their individual merits in this situation; CT is often more readily available and permits images to be acquired much more quickly than MRI. This is particularly of value in unstable patients.
CT images should be acquired in three phases: unenhanced, arterial and venous. The unenhanced images are used to locate the pancreas transplant and to identify vascular thromboses and haematomas, due to their increased attenuation. The arterial-phase study should be performed in an early angiographic phase, focused on the pancreas transplant. In our institution this is achieved by bolus tracking over the abdominal aorta and imaging at 7 s after the arrival of contrast medium. The arterial phase often demonstrates parenchymal enhancement and early venous drainage, depending on the transit time across the graft pancreas. The venous phase obtained 50 s post-injection (Fig. 3) of the whole abdomen and pelvis demonstrates graft venous drainage, parenchymal enhancement and fluid collections. Multi-detector CT (MDCT) enables 3D reconstructions (Fig. 4) of the vascular structures, which may enhance the detection of vascular complications.
SPK transplants may result in asymmetrical enhancement of the common iliac veins. This appearance is known as pseudothrombosis of the iliac vein . It results from the rapid transit time across the transplant kidney and early opacification of the iliac vein in comparison with the contralateral side.
Dynamic contrast enhanced MRI allows superior evaluation of the pancreatic parenchyma. Graft perfusion may be assessed and areas of necrosis demonstrated. Evaluation of the enteric anastomoses may be more difficult. MR angiography is considered to be inferior to CT angiography because of its limited spatial resolution.
MR cholangiopancreatography (MRCP) may be used to detect duct abnormalities. In cases of recurrent graft pancreatitis it can reveal both causes and consequences, e.g. pancreatic necrosis. Collections resulting from pancreatic leaks may be also demonstrated. Secretin-augmented MRCP has been used to show reduced exocrine function that may correlate with pancreatic rejection .
One factor that may limit the application of both CT and MRI is impaired renal transplant function, which is not uncommon in the immediate post-operative period. Under these circumstances both intravenous iodinated contrast media and gadolinium-based contrast media should be used with caution because of the respective risks of contrast-induced nephropathy and nephrogenic systemic fibrosis. Both CT and MRI may be applied without contrast media, depending upon the clinical indication. For instance, either modality could be used if a pseudocyst or collection is suspected.
Rejection is a common cause of pancreatic graft failure . For the period 2000-2004, the IPTR reported acute rejection to be the cause of graft failure in 7-25% of cases. Chronic rejection was reported to be the cause of graft failure in 2-33% of cases . Rejection has no specific imaging features. The cause of early graft failure is often difficult to determine clinically. Imaging therefore has a vital role in the exclusion of other causes of pancreatic graft failure and in guiding biopsy (Fig. 5).
The potential complications of pancreas transplant may be divided into three categories: those related to the vessels, those related to the graft parenchyma and those related to the enteric anastomoses.
Pancreas graft vascular complications
Graft thrombosis is the most common non-immunological cause of early graft failure. The incidence of graft thrombosis has been reported to range from 2 to 19% [19–26]. Venous thrombosis is more common than arterial thrombosis [27–29].
In venous thrombosis, US Doppler imaging demonstrates absent venous flow, and a high resistance arterial waveform, with reversed diastolic flow, may also be seen occasionally. Unenhanced CT may show thrombus as a high attenuation portal vein or splenic vein (Fig. 6a). A filling defect may be seen following the adminstration of intravenous contrast medium (Fig. 6b); but subtle thromboses may be obscured following parenchymal enhancement. Side-branch venous thromboses may be seen where small venous side branches have been ligated during retrieval. These are commonly of no clinical significance but are monitored to exclude the presence of thrombus propagation. Venous-graft thrombosis may result in pancreatic necrosis or duodenal stump breakdown, which usually necessitates graft pancreatectomy. Prompt diagnosis and immediate thrombectomy may be successful.
Graft arterial thrombosis is much less common than venous thrombosis, and can occur in the early or late phase post-transplantation. The thrombosis may also be seen as a hyperdense vessel on unenhanced CT, with subsequent non-enhancement following intravenous contrast medium (Fig. 7). Early arterial thrombosis may occur spontaneously at any of the anastomotic sites, or as a consequence of vascular rejection, and results in non-enhancement and subsequent necrosis of the pancreatic graft. Late arterial occlusion may represent the end point of graft rejection. This initially involves the smaller vessels and progresses to involve the larger ones .
Emphysematous transformation may occur within a necrotic graft. This is demonstrated on CT as gas locules within the pancreatic graft . It is impossible to differentiate between emphysematous transformation and gas-forming infection on CT. Scintigraphy with radioisotope-labelled white blood cells may be used as a suitable non invasive alternative, where there is clinical uncertainty regarding the presence of graft associated infection (Fig. 8). However, in this situation, surgical graft exploration is usually indicated.
Haemorrhage may result from failure of the arterial anastomoses, but more commonly occurs where the superior mesenteric vessels or splenic vessels have been ligated. A haematoma may be demonstrated as a high attenuation collection on an initial unenhanced CT series. Contrast extravasation may then be detected in the arterial and/or venous phases. While significant intra–abdominal bleeding after pancreas transplantation remains one of the most common reasons for relaparotomy, less than 0.3% of all pancreas grafts are lost as a result of haemorrhage .
Pseudoaneurysms, arteriovenous fistulae, arterial dissection and arterial stenosis represent some rarer vascular complications. Pseudoaneurysms may be the result of surgical technique (particularly if the mesenteric pedicle has been divided with a linear stapling device), infection, severe pancreatitis, or allograft biopsy. Arteriovenous fistulae may be the result of vascular injury, either at surgery or post-biopsy; they are common in the stapled edge of the mesentery where the superior mesenteric vessels have been divided. Arterial stenosis can arise at any anastomosis and may ultimately lead to reduced graft perfusion (Fig. 9). Occasionally, the arterial “Y graft” conduit may kink; this can result in significant haemodynamic compromise and graft dysfunction. Furthermore, the donor portal vein may appear kinked proximal to the anastomosis with the recipient IVC. It is yet to be determined whether this is clinically significant. Our experience suggests that this does not cause graft dysfunction.
CT angiography is the best tool in the initial assessment of these vascular complications. Conventional angiography is used to confirm vascular abnormalities which may then be amenable to endovascular therapy.
Pancreatic parenchymal graft complications are an important cause of morbidity in the early post-operative period. These complications include acute rejection, pancreatitis, pseudocyst formation, and infection with abscess formation.
The exact incidence of post-transplant pancreatitis is very difficult to determine because of the lack of a universally accepted definition [33–35]. Prolonged hyperamylasaemia is seen early post transplant in up to 35% of all recipients . Unfortunately amylase and lipase levels correlate poorly with the severity of graft pancreatitis , making evaluation of the true incidence of graft pancreatitis near impossible.
Early graft pancreatitis is often due to reperfusion injury and usually involves the whole graft (Fig. 10). In the early post-operative period, ill-defined fat planes around the pancreatic graft are commonly seen. The graft may appear as an enhancing ‘mass’ surrounded by an omental wrap in the right iliac fossa. At an early stage it may be difficult to distinguish radiologically between the appearance of the normal post operative pancreatic graft and early graft pancreatitis. Furthermore, focal oedema of the donor’s mesenteric fat attached to the SMA stump, presumably the result of donor lymphatic vessel ligation, should not be misinterpreted as focal oedematous pancreatitis . MDCT is valuable in evaluating the complications of pancreatitis, such as parenchymal necrosis and abscess formation. Collections may be amenable to image-guided drainage to alleviate the pressure effect on the vascular supply and drainage of the pancreatic graft.
Repeated episodes of pancreatitis may be secondary to ampullary or duodenal anastomotic stricture or mucus plugging. MRCP may be of diagnostic use in this situation. Mucus plugging may cause focal or generalised duct dilatation, whereas an ampullary or anastomotic stricture will result in generalised duct dilatation in the absence of a pancreatic duct stricture. US can show a bulky pancreas, possibly with associated fluid collections. However, interpretation may be hampered by poorly defined pancreatic margins. Both CT and US may be used to guide percutaneous abscess drainage.
Pseudocysts form at a later stage as a result of graft pancreatitis. They may occur inside or outside the graft and have the potential to become infected. This may result in vascular pseudoaneurysm formation. The diagnosis should be considered in patients with a pulsatile abdominal mass, unexplained anaemia and/or haemodynamic instability, and when there is rapid enlargement of a pseudocyst. CT angiography is used to evaluate this possibility. Formal angiography is subsequently used to confirm the presence of a pseudoaneurysm (Fig. 11) and permit embolisation.
Another potential complication of pancreatitis is fistula formation. Fistulae may form between the pancreatic graft and the skin or the peritoneal cavity (Fig. 12). Sinus tracts may also develop. Fistulae connecting to the skin are best assessed with CT fistulograms. Internal fistulae are best assessed with MRI.
Thickening of the bowel loops surrounding the pancreas graft frequently occurs in the post-operative period, often due to manipulation during the surgical procedure, the formation of a Roux loop and aggressive rehydration. This usually resolves within 3–4 weeks. The donor duodenum may also appear thick-walled .
Duodenal segment leaks may occur at the duodenojejunostomy, but are more common at the staple line of the duodenal stump (Fig. 13). These occur early due to ischaemia, or late (>4 weeks) secondary to infection or rejection. Free air around the graft is common in the early post-operative period, but seen late may indicate an anastomotic leak. Free fluid may also be seen and collections may form adjacent to the leaking point.
Small bowel obstruction is most commonly secondary to adhesions, a generic risk of abdominal surgery (Fig. 14). Another potential cause is internal herniation of jejunal loops posterior to the pancreatic graft, through a mesenteric defect related to the Roux loop formation .
Complications of immunosuppressive therapy may manifest in the bowel. Rarely, a neutropenic typhlitis may develop. Alternatively, opportunistic infections with organisms such as cytomegalovirus, or antibiotic-associated Clostridium difficile may cause colitis.
Complications secondary to immunosuppression
The common complications secondary to immunosuppression seen in solid organ transplantation are generally categorised as related to either infection or tumour. We would like to highlight the specific complication of post-transplant lymphoproliferative disorder (PTLD) that can be diagnosed using cross-sectional imaging. PTLD is a serious but rare complication of pancreas transplantation. It has a reported incidence after pancreatic transplantation of 3-12% [38, 39]. It is associated with the higher levels of immunosuppression needed in SPK transplants compared with other solid organ transplants. It is associated with a donor acquired EBV infection and is therefore commoner in younger previously EBV-naive transplant recipients, for example, type I DM recipients of SPK grafts. Diffuse enlargement of the pancreatic graft is a common manifestation, which is indistinguishable from oedematous pancreatitis or transplant rejection. Less commonly focal intra- or extra-allograft masses may develop (Fig. 15), and lymphadenopathy and other organomegaly may also occur . A tissue diagnosis is essential as the treatment modalities include a reduction in immunosuppression and consideration of chemotherapy.
With the increasing number of pancreatic transplants that are now being performed, it is vital that radiologists understand the complex post-operative anatomy and the potential complications of transplantation. By doing this, they can use the diagnostic tools available to them to their full potential. It is crucial that surgical and radiology teams liaise in these patients, in order that the radiologists are familiar with the local operative technique. This enables the imaging to be tailored to the patient and will increase the accuracy of image interpretation. In addition, by performing percutaneous drainage procedures, biopsies and endovascular therapies, radiologists have an important role to play in the management of many complications.
Gruessner AC, Sutherland DE (2005) Pancreas transplant outcomes for United States (US) and non-US cases as reported to the United Network for Organ Sharing (UNOS) and the International Transplant Registry (IPTR) as of June 2004. Clin Transplant 19:433–455
Farney AC, Cho E, Schweitzer EJ, Dunkin B, Philosophe B, Colonna J et al (2000) Simultaneous cadaver pancreas living-donor kidney transplantation: a new approach for type 1 diabetic uremic patient. Ann Surg 232:696–03
Freund MC, Steurer W, Gassner EM, Unsinn KM, Rieger M, Koenigsrainer A et al (2004) Spectrum of imaging findings after pancreas transplantation with enteric exocrine drainage: part 1, posttransplantation anatomy. AJR 182:911–917
Zielinski A, Nazarewski S, Bogetti D, Sileri P, Testa G, Sankary H et al (2003) Simultaneous pancreas-kidney transplant from living related donor: a single-center experience. Transplantation 76(3):547–552
Aideyan OA, Foshager MC, Benedetti E, Troppmann C, Gruessner RW (1997) Correlation of the arterial resistive index in pancreas transplants of patients with transplant rejection. AJR Am J Roentgenol 168:1445–1447
Wong JJ, Krebs TL, Klassen DK, Daly B, Simon EM, Bartlett ST et al (1996) Sonographic evaluation of acute pancreas transplant rejection: morphology-Doppler analysis versus guided percutaneous biopsy. AJR Am J Roentgenol 166:803–807
Sollinger HW, Knechtle SJ, Reed A, D’Alessandro AM, Kalayoglu M, Belzer FO et al (1991) Experience with 100 consecutive simultaneous kidneypancreas transplants with bladder drainage. Ann Surg 214:703–711
Troppmann C, Gruessner AC, Benedetti E, Papalois BE, Dunn DL, Najarian JS et al (1996) Vascular graft thrombosis after pancreatic transplantation: univariate and multivariate operative and nonoperative risk factor analysis. J Am Coll Surg 182(4):285–316
Sansalone CV, Maione G, Aseni P, Mangoni I, De Roberto A, Soldano S et al (2005) Surgical complications are the main cause of pancreatic allograft loss in pancreas-kidney transplant recipients. Transplant Proc 37:2651–2653
Gruessner AC, Sutherland DER (2009) Pancreas transplant outcomes for United States (US) cases as reported to the United Network for Organ Sharing (UNOS) and the International Pancreas Transplant Registry (IPTR). In: Cecka JM, Terasaki (eds) Clinical transplants 2008. UCLA Tissue Typing Laboratory, Los Angeles, pp 45–56
Troppmann C, Gruessner AC, Dunn DL, Sutherland DE, Gruessner RW (1998) Surgical complications requiring early relaparotomy after pancreas transplantation: a multivariate risk factor and economic impact analysis of the cyclosporine era. Ann Surg 227:255–268
Small RM, Shetzigovski I, Blachar A, Sosna J, Klausner JM, Nakache R et al (2008) Redefining late acute graft pancreatitis: clinical presentation, radiologic findings, principles of management, and prognosis. Ann Surg 247:1058–1063
Freund MC, Steurer W, Gassner EM, Unsinn KM, Rieger M, Koenigsrainer A et al (2004) Spectrum of imaging findings after pancreas transplantation with enteric exocrine drainage: part 2, Posttransplantation complications. AJR Am J Roentgenol 182:919–925
